Made In USA Reducing Coupling Malleable Iron 1-1/2-11-1/2 x 3/4-14
(Pack of
1.0)
150 lb. Rated, Black and Galvanized
• Class 150
• Black and Galvanized
ASC Engineered Solutions™ offers the broadest line of malleable iron fitting sizes in both black and galvanized finishes. Every fitting is manufactured and tested to meet ASC's strict quality standards. All Anvil Class 150 Malleable Iron Fittings conform to ASME B16.3 and unions conform to ASME B16.39. All elbows and tees 3/8" (10 DN) and larger are 100% gas tested at a minimum of 100 PSI (6.9 bar).
• Made in USA
• Dimension: ASME B16.3
• Material: ASTM A197
• Galvanizing: ASTM A153
• Thread: ASME B1 20.1
• Pressure Rating: ASME B16.3
• Finish: Black or Galvanized
• UL Listed
• FM approved
Frequently Bought Together
Polyethylene Tubing 1/4" OD x 100' Yellow
Couldn't load pickup availability
Polyethylene Tubing 1/4" OD x 100' Red
Couldn't load pickup availability
Polyethylene Tubing 3/8" OD x 100' Yellow
Couldn't load pickup availability
Push-Button Air Coupler Plug Steel 1/4" x 1/4-18
Couldn't load pickup availability
Hose Nozzle Twist Brass Hose Nozzle Twist
Couldn't load pickup availability
Hose End Brass 3/8 x 3/8"
Couldn't load pickup availability
Made In USA Reducing Elbow Malleable Iron 2-1/2-8 x 2-11-1/2
Couldn't load pickup availability
Made In USA Pipe Tee Malleable Iron 1-11-1/2 x 1-11-1/2 x 1-11-1/2
Couldn't load pickup availability
Hex Bushing Steel 2-11-1/2 x 1-1/4-11-1/2
Couldn't load pickup availability
Front Bumper Drive Rivet Plastic 10mm Hole
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Couldn't load pickup availability
Product Description
150 lb. Rated, Black and Galvanized• Class 150
• Black and Galvanized
ASC Engineered Solutions™ offers the broadest line of malleable iron fitting sizes in both black and galvanized finishes. Every fitting is manufactured and tested to meet ASC's strict quality standards. All Anvil Class 150 Malleable Iron Fittings conform to ASME B16.3 and unions conform to ASME B16.39. All elbows and tees 3/8" (10 DN) and larger are 100% gas tested at a minimum of 100 PSI (6.9 bar).
• Made in USA
• Dimension: ASME B16.3
• Material: ASTM A197
• Galvanizing: ASTM A153
• Thread: ASME B1 20.1
• Pressure Rating: ASME B16.3
• Finish: Black or Galvanized
• UL Listed
• FM approved
Technical Specifications
| Item#: | 1637885 |
|---|---|
| Fitting Type | Pipe |
| Material | Malleable Iron |
| Class | 150 lb. |
| Configuration | Reducing Coupling |
| Connection Type A x B | Female NPT x Female NPT |
| Fitting Dimension A | 1-1/2-11-1/2 |
| Fitting Dimension B | 3/4-14 |
| Finish | Black |
| Quantity Per Package | 1 ea. |
| UNSPSC #: | 40173606 |
| TAA Compliant: | Yes |
| Weight: | 0.87 lb |
