Push and Lock 8 Wire Connector 30A Black
(Pack of
50.0)
• Easy-to-use connector for making wire splices
• Each wire is individually locked in the connector
• Strip the insulation from the end of the wire and push the wire into the connector – the connector locks onto the wire conductor making a permanent connection
• See-through housing allows easy visual installation – wire locks easily into terminal
• UL/ULC listed for solid wire• Rated 30A, 600V AC maximum for building wire, 1,000V maximum for signs and lighting fixtures• Temperature range: –42°F to +221°F (–30°C to +105°C)
• Use with 12 to 22 Ga. wire sizes
• Ideal for lighting repairs and installations, in junction boxes for wiring switches and outlets, and for security/alarm systems
• Can also be used on vehicle and transportation 12V/24V applications using stranded wire
Frequently Bought Together
Energizer® AAA Alkaline Battery 1.5V
Couldn't load pickup availability
Insulform Heat Shrink Tubing 22 to 18 AWG Black
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 20 to 18 AWG Black
Couldn't load pickup availability
Push and Lock 4 Wire Connector 30A Yellow
Couldn't load pickup availability
3 Wire Lever-Nut Connector 28-12 Awg
Couldn't load pickup availability
5 Wire Lever-Nut Connector 28-12 Awg
Couldn't load pickup availability
Air Distributor Defroster Push-Type Retainer
Couldn't load pickup availability
Front Bumper Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Nylon Cable Tie 11-3/4" Black
Couldn't load pickup availability
Wire Nut Twister 14-8 AWG Gray
Couldn't load pickup availability
Wire Connector 22 to 14 AWG Blue
Couldn't load pickup availability
Winged Wire Connector 14 to 10 AWG Green
Couldn't load pickup availability
Product Description
• Easy-to-use connector for making wire splices• Each wire is individually locked in the connector
• Strip the insulation from the end of the wire and push the wire into the connector – the connector locks onto the wire conductor making a permanent connection
• See-through housing allows easy visual installation – wire locks easily into terminal
• UL/ULC listed for solid wire• Rated 30A, 600V AC maximum for building wire, 1,000V maximum for signs and lighting fixtures• Temperature range: –42°F to +221°F (–30°C to +105°C)
• Use with 12 to 22 Ga. wire sizes
• Ideal for lighting repairs and installations, in junction boxes for wiring switches and outlets, and for security/alarm systems
• Can also be used on vehicle and transportation 12V/24V applications using stranded wire
Technical Specifications
| Item#: | 64659 |
|---|---|
| Type | Standard |
| Wire Capacity | 8 Wire |
| Color | Black |
| Rating | 30A, 600VC maximum for building wire, 1,000V maximum for signs and lighting fixtures A |
| Temperature Range | -42 to 221 °F |
| Approvals | UL/ULC listed for solid wires |
| Style | Push and Lock Wire Connectors |
| UNSPSC #: | 39121409 |
| TAA Compliant: | No |
| Weight: | 0.54 lb |
Product Restrictions
