Snap Receptacle Terminal, Nylon Insulated, 16 to 14 AWG, 11/64" Snap Diameter, Blue
(Pack of
50)
SKU:82918 Item#: 82918
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.
Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper for the highest conductivity• Annealed to flow freely under crimping pressure for best connection• Electro-tin-plated for greatest corrosion resistance• 600V
Couldn't load pickup availability
Catalog page#: 2-21
Frequently Bought Together
Miniature Incandescent Bulb 12V
Couldn't load pickup availability
Miniature Incandescent Bulb 12V 37CP
Couldn't load pickup availability
Rechargeable Neck Light
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
Couldn't load pickup availability
Acrysol Auto Body Degreaser 16oz
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
Couldn't load pickup availability
22-18 AWG, Visa Seal™ Female Snap .180 Dia, Red
Couldn't load pickup availability
Snap Plug Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Snap Receptacle Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Butt Connector 12 to 10 AWG
Couldn't load pickup availability
Closed End Connector 600V 16 to 10 AWG Blue
Couldn't load pickup availability
Poly Vinyl Terminal Assortment 825Pcs
Couldn't load pickup availability
Product Description
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper for the highest conductivity• Annealed to flow freely under crimping pressure for best connection• Electro-tin-plated for greatest corrosion resistance• 600V
Technical Specifications
| Item#: | 82918 |
|---|---|
| Type | Crimp |
| Style | Vinyl-Insulated |
| Wire Gauge | 16-14 AWG |
| Receptacle Diameter | 11/64 " |
| Color | Blue |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.12 lb |
