ASTM A-193 Threaded Stud, Grade B7, Alloy Steel, Plain Finish, Coarse Thread, 125000PSI Strength, 3/4-10 x 3"
(Pack of
5)
SKU:96418 Item#: 96418
• Unplated
• Stamped B7 on one end for material identification purposes
• Fully chamfered ends
• UNC coarse threads
• Conforms to ASTM A193 and ASME SA193 B7 specifications
• 125,000 PSI minimum tensile strength at room temperature. For maximum allowable stress value at specific temperatures, refer to ASME Boiler and Pressure Code Section VIII.
Used in most piping and flange applications requiring a high-strength ferrous steel bolt capable of operating in a temperature range of –20°F to +750°F (–29°C to +399°C) when used with Grade 2H nuts.
Couldn't load pickup availability
Catalog page#: 11-55
Frequently Bought Together
Product Description
• Unplated• Stamped B7 on one end for material identification purposes
• Fully chamfered ends
• UNC coarse threads
• Conforms to ASTM A193 and ASME SA193 B7 specifications
• 125,000 PSI minimum tensile strength at room temperature. For maximum allowable stress value at specific temperatures, refer to ASME Boiler and Pressure Code Section VIII.
Used in most piping and flange applications requiring a high-strength ferrous steel bolt capable of operating in a temperature range of –20°F to +750°F (–29°C to +399°C) when used with Grade 2H nuts.
Technical Specifications
| Item#: | 96418 |
|---|---|
| Diameter | 3/4 " |
| Thread Pitch | 10 |
| Thread | Coarse |
| Length | 3 " |
| Grade | B7 |
| Material | Alloy Steel |
| Type | B7 Alloy Studs |
| Finish | Plain |
| Strength | 125,000 PSI |
| Specifications | ASTM A 193 B7 |
| Size | 3/4X3 " |
| UNSPSC #: | 31163300 |
| TAA Compliant: | No |
| Weight: | 1.58 lb |
