264 For Carbide And Difficult To Braze Materials 70000 Tensile 16.8 Iacs Elongation 34% Low Melting Point
(Pack of
6)
SKU:EG26470000 Item#: EG26470000
A cadmium free, high silver alloy designed for joining carbide tips to tool shanks. Excellent for difficult to braze materials, including tungsten carbide, carbon and low alloy steels, and stainless steels.
• Low Temperature – Easy flowing
• Excellent Capillary Action – Assures sound joints
• Cadmium free
• Absorbs impact and shock
• Superior wetting action and joint toughness
• Forms a fillet in the joint for added strength
• Joint Strength: Up to 70,000 PSI/482 MPa
• Elongation: 34%
• Working Temperature: 1435°F/779°C
• Electrical Conductivity: 16.8% IACS
Frequently Bought Together
30 Copper and Steel Flux Coated Brazing Rod 1/8"
$0.00
Couldn't load pickup availability
47 Sil-Phos Bare Brazing Rod 1/8"
$0.00
Couldn't load pickup availability
266 Pink Flux Coated Super Fast Flowing Silver Brasing Alloy 3/64X18
$0.00
Couldn't load pickup availability
Bumper Fascia General Purpose Split Rivet 3/16"
$0.00
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
$0.00
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
$0.00
Couldn't load pickup availability
40 High Silver Flux Coated Brazing Rod 1/16"
$0.00
Couldn't load pickup availability
51 High Silver Flux Coated Brazing Rod 1/16"
$0.00
Couldn't load pickup availability
41 Silver Flux Coated Brazing Rod 1/16"
$0.00
Couldn't load pickup availability
333 Dissimilar Steel Stick Rod Electrode 3/32"
$0.00
Couldn't load pickup availability
Large MIG Plier
$0.00
Couldn't load pickup availability
11-35 MIG Welding Contact Tip 0.035"
$0.00
Couldn't load pickup availability
Product Description
A cadmium free, high silver alloy designed for joining carbide tips to tool shanks. Excellent for difficult to braze materials, including tungsten carbide, carbon and low alloy steels, and stainless steels.• Low Temperature – Easy flowing
• Excellent Capillary Action – Assures sound joints
• Cadmium free
• Absorbs impact and shock
• Superior wetting action and joint toughness
• Forms a fillet in the joint for added strength
• Joint Strength: Up to 70,000 PSI/482 MPa
• Elongation: 34%
• Working Temperature: 1435°F/779°C
• Electrical Conductivity: 16.8% IACS
Technical Specifications
| Item#: | EG26470000 |
|---|---|
| Welding Process | Brazing |
| Type | Bare Brazing Rod |
| Diameter | 1/16 " |
| Length | 18 " |
| Tensile Strength | 90,000 PSI |
| Melting Temperature | 1,435 °F |
| Color | Shiny Grey |
| Base Metal | All Metals Except White Metals |
| Recommended Flux | 361 |
| UNSPSC #: | 23271804 |
| TAA Compliant: | Yes |
| Weight: | 0.33 lb |
