Flexible Battery Cable, 4 AWG, Total Strands 399, 25' Length, Black, 600 Volts, Gray-Crimp Color Code, Copper Conductor
(Pack of
1)
• Contains up to three times the strand count of regular battery cables
• Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
• Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
• Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
•Temperature range: –56.2°F to +221°F (–49°C to +105°C)
• 600V maximum
• SAE J378C / J1127
• Marine rated
• A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 2-69
Frequently Bought Together
Battery Cable 4 AWG Black Gray-Crimp Code
Couldn't load pickup availability
Flexible Battery Cable 3/0 AWG Black 25'
Couldn't load pickup availability
Battery Cable 3/0 AWG 50' Purple
Couldn't load pickup availability
Halogen Miniature Bulb 55W 12V
Couldn't load pickup availability
Lithium Battery #2025 3V
Couldn't load pickup availability
Energizer® AAA Alkaline Battery 1.5V
Couldn't load pickup availability
Solder Slug Assortment 6-4/0 AWG 201Pcs
Couldn't load pickup availability
Stop/Tail/Turn Lamp Red US 440 Series LH
Couldn't load pickup availability
Stop/Tail/Turn Lamp Red Sealed
Couldn't load pickup availability
Rivet Nylon 1/4"
Couldn't load pickup availability
Front Bumper Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Radiator Grille Nut M4.2-1.41
Couldn't load pickup availability
N-Ferno 6472 Insulated Bib Overalls - 300D Oxford Shell
Couldn't load pickup availability
N-Ferno 6472 Insulated Bib Overalls - 300D Oxford Shell
Couldn't load pickup availability
N-Ferno 6472 Insulated Bib Overalls - 300D Oxford Shell
Couldn't load pickup availability
Product Description
• Contains up to three times the strand count of regular battery cables• Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
• Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
• Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
•Temperature range: –56.2°F to +221°F (–49°C to +105°C)
• 600V maximum
• SAE J378C / J1127
• Marine rated
• A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Technical Specifications
| Item#: | P52478 |
|---|---|
| Cable Gauge | 4 |
| Total Strands | 399 |
| Color | Black |
| Volts | 600 V |
| Minimum Temperature Rating | -40 °F |
| Maximum Temperature Rating | 221 °F |
| Length | 25 ft |
| Crimp Color Code | Gray |
| Amperage Capacity at 140°F (60°C) | 105 A |
| Amperage Capacity at 167°F (75°C) | 125 A |
| Amperage Capacity at 194°F (90°C) | 140 A |
| Specifications | SAE J378C/J1127, UL 62-SJE,SE,SEO |
| Style | Premium Flexible |
| Type | Battery Cable |
| UNSPSC #: | 39121405 |
| TAA Compliant: | Yes |
| Weight: | 5.61 lb |
