Flexible Battery Cable 8 AWG Red 25'
(Pack of
1.0)
Contains up to three times the strand count of regular battery cables
Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
Temperature range: 56.2°F to +221°F (49°C to +105°C)
600V maximum
SAE J378C / J1127
Marine rated
A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog Page#: 2-69
Frequently Bought Together

Battery Cable 2 AWG Red Green-Crimp Code
Couldn't load pickup availability

Flexible Battery Cable 8 AWG Black 25'
Couldn't load pickup availability

Flexible Battery Cable 6 AWG Red 50'
Couldn't load pickup availability

Standard Size Alligator Clip 5A Steel Yellow
Couldn't load pickup availability

Multiple-Feature Test Prod with 90° Plugs
Couldn't load pickup availability

Standard Size Alligator Clip 5A Steel Yellow
Couldn't load pickup availability

Stop/Tail/Turn Lamp Red Economy
Couldn't load pickup availability

Female Terminal for GM Vehicle 12 AWG
Couldn't load pickup availability

Female Terminal for GM Vehicle 10 AWG
Couldn't load pickup availability

Wire Stripper-Cutter 6" Stainless Steel Jaws
Couldn't load pickup availability

Bumper Drive Rivet Plastic 10mm Hole
Couldn't load pickup availability

Fender Lining Screw Grommet Nylon #12
Couldn't load pickup availability
Product Description
Contains up to three times the strand count of regular battery cables Extra high count, rope-stranded, electrolytic copper conductors ensure maximum conductivity and cool operation
Unique extruded inner yellow sleeve lies between conductors and outer jacket to provide an extra margin of protection against corrosion and cut-through
Premium thermoplastic rubber insulation jacket provides the best overall chemical, heat, cold and flame resistance; highly resistant to UV light and ozone exposure; remains flexible over a long service life
Temperature range: 56.2°F to +221°F (49°C to +105°C)
600V maximum
SAE J378C / J1127
Marine rated
A superior, high-performance battery cable for automotive and marine applications, as well as industrial and institutional battery backup power systems
Technical Specifications
Item#: | P52436 |
---|---|
Cable Gauge | 8 |
Total Strands | 168 |
Color | Red |
Volts | 600 V |
Minimum Temperature Rating | -40 °F |
Maximum Temperature Rating | 221 °F |
Length | 25 ft |
Crimp Color Code | Red |
Amperage Capacity at 140°F (60°C) | 60 A |
Amperage Capacity at 167°F (75°C) | 70 A |
Amperage Capacity at 194°F (90°C) | 80 A |
Specifications | SAE J378C/J1127, UL 62-SJE,SE,SEO |
Style | Premium Flexible |
Type | Battery Cable |
UNSPSC #: | 39121405 |
TAA Compliant: | Yes |
Weight: | 3.53 lb |
