Male Quick Slide Terminal, Fully Insulated, Nylon, 22 to 18 AWG, 1/4" Tab Width, Red
(Pack of
100)
Designed for medium-gauge wires, this quick-connect slide is ideal for mechanical and industrial applications. The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection. Reusable and the fastest way to connect and disconnect two wires.
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Nylon insulation provides high-quality, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• 600V
• Male – Dimpled tabs help hold the two connectors together even in high vibration conditions
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Female Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Female Disconnect Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Male Quick Slide Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Energizer® AA Alkaline Battery 1.5V
Couldn't load pickup availability
MINI Fuse 15A Blue
Couldn't load pickup availability
Butt Connector 22 to 24 AWG Clear
Couldn't load pickup availability
Phillips Truss Head Sheet Metal Screw Steel 15mm
Couldn't load pickup availability
Front License Plate to Bumper Cover Split Rivet
Couldn't load pickup availability
Front Bumper and Radiator Support Drive Rivet
Couldn't load pickup availability
Sure-Lok Wire Connector 22 to 8 AWG Red
Couldn't load pickup availability
Sure-Lok Wire Connector 22 to 12 AWG Yellow
Couldn't load pickup availability
Winged Wire Connector 14 to 8 AWG Gray
Couldn't load pickup availability
Female Terminal for GM Vehicle 16-14 AWG
Couldn't load pickup availability
1/4-20X3/4 Male Dyna Base Mount Reactangle
Couldn't load pickup availability
E7018 Mild/Carbon Steel Stick Electrode 3/16"
Couldn't load pickup availability
Product Description
Designed for medium-gauge wires, this quick-connect slide is ideal for mechanical and industrial applications. The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection. Reusable and the fastest way to connect and disconnect two wires.• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Nylon insulation provides high-quality, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• 600V
• Male – Dimpled tabs help hold the two connectors together even in high vibration conditions
Technical Specifications
| Item#: | 1145947 |
|---|---|
| Type | Crimp |
| Wire Gauge | 22-18 AWG |
| Tab Width | 1/4 " |
| Connection Type | Male |
| Color | Red |
| Description | Quick Slide - Fully Insulated |
| Style | Electro-Lok Fully-Insulated Quick Slides |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.36 lb |
