3/4 x 4" Yellow Thermapod Heat Shrink Tube
(Pack of
1.0)
Thermal Shrinkable Wire Protection
Double Layer . . . Double Protection
• Thermapod™ is an easy-to-use heat-shrink system that protects wire connections from 4/0 cable down to 22-gauge wire. Almost any heat source will convert the Thermapod™ into a moisture-resistant, tailor-fit covering for wire connection
• Combines a sealant inner layer and a tough, abrasion-resistant outer cover
• The shrinking outer layer forces the liquid inner layer into the crevices and spaces of the wires or cable for a moisture-resistant, perfect fit
• When the two layers cool, they become a semi rigid, protective “pod” that seals the wiring from the environment
• Improved encapsuliation and strain damage from flexing
• Temperature Rating: -67°F to +230°F/ -55°C to +110°C
• Shrink Temperature: 275°F/135°C
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Nylon Cable Tie 4" Black
Couldn't load pickup availability
Solder Slug 4 AWG Gray 6s Pre-Heat Time
Couldn't load pickup availability
Heavy-Duty Battery Cable Lug 4 AWG Gray 5/16"
Couldn't load pickup availability
3/8 x 3" Red Thermapod Heat Shrink Tube
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 10 to 8 AWG Black
Couldn't load pickup availability
Heat Shrink Tubing Assortment 5 Items 38Pcs
Couldn't load pickup availability
Bumper Radiator and Grille Drive Rivet 7mm Hole
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
Couldn't load pickup availability
Snap Bushing Nylon Black 2-15/32"
Couldn't load pickup availability
Tite-Seal II Cord and Cable Grip PG-9
Couldn't load pickup availability
Seal Tite Fusion Wrap Black 1"
Couldn't load pickup availability
Product Description
Thermal Shrinkable Wire ProtectionDouble Layer . . . Double Protection
• Thermapod™ is an easy-to-use heat-shrink system that protects wire connections from 4/0 cable down to 22-gauge wire. Almost any heat source will convert the Thermapod™ into a moisture-resistant, tailor-fit covering for wire connection
• Combines a sealant inner layer and a tough, abrasion-resistant outer cover
• The shrinking outer layer forces the liquid inner layer into the crevices and spaces of the wires or cable for a moisture-resistant, perfect fit
• When the two layers cool, they become a semi rigid, protective “pod” that seals the wiring from the environment
• Improved encapsuliation and strain damage from flexing
• Temperature Rating: -67°F to +230°F/ -55°C to +110°C
• Shrink Temperature: 275°F/135°C
Technical Specifications
| Item#: | DY21863353 |
|---|---|
| Type | Pre-Cut |
| Style | Dual Wall |
| Wire Gauge Coverage | 2/0- 2 AWG |
| Diameter | 3/4 " |
| Length | 4 ft |
| Color | Yellow |
| I.D. Before Shrinkage | 0.75 " |
| I.D. After Shrinkage | 0.313 " |
| Shrink Ratio | 3:1 |
| Dielectric Strength | 500 V/mil |
| Temperature Rating | -67°F to 230°F/ -55°C to 110°C |
| Shrink Temperature | 275°F/135°C |
| Tensile Strength | 1,500 PSI |
| Approvals | SAE-AMS-DTL - 23053/4, CL-1 |
| Description | Thermapod Heat Shrink Tubing Yellow 3/4 x 4' |
| UNSPSC #: | 39121723 |
| TAA Compliant: | Yes |
| Weight: | 0.72 lb |
