Carriage Bolt, Round Head, Grade 2, Steel, Zinc Finish, Coarse Thread, 5/8-11 x 1-1/2"
(Pack of
25)
SKU:4178 Item#: 4178
• UNC threads
• Full thread up to and including 6" long; over 6" long have 6" threads
• Zinc finish
• Conforms to SAE J429 and ANSI B18.5
Frequently Bought Together
Hex Flange Bolt Grade 10.9 M8-1.25 x 35mm
Item#: 28688
$0.00
Couldn't load pickup availability
DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 20mm
Item#: 59412
$0.00
Couldn't load pickup availability
Hex Cap Screw Property Class 8.8 M10-1.5 x 30mm
Item#: 61270
$0.00
Couldn't load pickup availability
Carriage Bolt Grade 5 5/8-11 x 5"
Item#: CB2011
$0.00
Couldn't load pickup availability
Carriage Bolt Grade 2 Steel #10-24 x 2"
Item#: 92917
$0.00
Couldn't load pickup availability
Carriage Bolt Grade 2 Steel 5/8-11 x 5"
Item#: 62676
$0.00
Couldn't load pickup availability
Serrated Hex Flange Nut Alloy Steel M10-1.25
Item#: 28701
$0.00
Couldn't load pickup availability
Hex Nut Grade 8 Steel M10-1.5
Item#: 4305
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 12mm
Item#: 28678
$0.00
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Item#: 2539
$0.00
Couldn't load pickup availability
Hex Nut Grade 8 Steel M12-1.75
Item#: 80250
$0.00
Couldn't load pickup availability
Hex Flange Nut Grade 8 Steel M8-1.25
Item#: 57129
$0.00
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
Item#: P85316
$0.00
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
Item#: KT13321
$0.00
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
Item#: KT12848
$0.00
Couldn't load pickup availability
Product Description
• UNC threads• Full thread up to and including 6" long; over 6" long have 6" threads
• Zinc finish
• Conforms to SAE J429 and ANSI B18.5
Technical Specifications
| Item#: | 4178 |
|---|---|
| Type | Carriage Bolt |
| Diameter | 5/8 " |
| Thread Pitch | 11 |
| Thread | Coarse |
| Length | 1-1/2 " |
| Grade | 2 |
| Finish | Bright Zinc |
| Head Style | Round |
| Material | Carbon Steel |
| Thread Length | Full |
| Thread Form | UNR |
| Size | 5/8-11 " |
| Neck Style | Square |
| UNSPSC #: | 31161603 |
| TAA Compliant: | No |
| Weight: | 4.82 lb |
