Confined Space Kit with Tripod, 60 ft 3-Way Self-Retracting Lifeline with Rescue Capability, Pulley, Self-Locking Carabiner, Hoist Bracket, Aluminum
(Pack of
1)
SKU:1648719 Item#: 1648719
The Werner T700000X Confined Space Kit includes the T100108 8ft Aluminum Tripod, the T410060 60-foot 3-Way Self-Retracting Lifeline with Rescue Capability (SRL-R), T510045 60-foot Material Hoist, and T200007 Pulley and Carabiner. Two T100008B Mounting Brackets attach the 60-foot 3-Way SRL-R and the 60-foot Material Hoist to any leg of the tripod. Also included is the T510080B Hoist Bracket that attaches the 60-foot Material Hoist. The Tripod extends from 58-97-inches in height for installation over openings with a maximum diameter of 42-inches when fully extended and meets the requirements of ANSI Z359.18-2017 Type A. The 3-Way SRL-R is designed for a single user with a capacity up to 310 pounds total working weight and has an aluminum housing with a lifting ratio of 6.5:1. When tested to the requirements of the ANSI Z359.14-2021 standard for Class 1 for SRLs, the 3-Way SRL-R has an average arrest force of 1,350 pounds and a maximum arrest distance of 24-inches. The hoist is capable of raising and lowering loads of up to 450 pounds. The Material Hoist has 60 feet of 3⁄16-inch diameter galvanized steel cable.
• Confined Space Kit with Tripod, 60-foot 3-Way SRL-R, Bracket, Pulley, Carabiner, Hoist Bracket, and 60-foot Hoist
• Confined Space Kit includes T100108 8ft Aluminum Tripod, the T410060 60-foot 3-Way SRL-R, (2) T100008B Mounting Brackets, T510080B Hoist Bracket, T510045 60-foot Material Hoist and T200007 Pulley and carabiner
• High strength, lightweight Aluminum Tripod extends from 58-inches to 97-inches in height
• Tripod meets ANSI Z359.18-2017 Type A and OSHA regulations
• The 60-foot 3-Way SRL-R has maximum arrest distance of 24-inches
• 3-Way SRL-R meets ANSI z359.14-2021 Class 1 SRL-R and OSHA Standards
• Material Hoist is capable of raising and lowering loads of up to 450 lbs.
• Pulley is for use with up to a 3/16-inch diameter steel cable and has an 8,100 lbs. tensile breaking strength
Frequently Bought Together
Wire Sling Loop, Red, One Size, Premium Coated Stainless Steel Cable Wire, 2 lb Maximum Load Lmit
$0.00
Couldn't load pickup availability
Wire Sling with Screw Gate, Orange, One Size, Coated Stainless Steel Cable Wire, 3 lb Max Load Lmit
$0.00
Couldn't load pickup availability
Webbing Tool Connector, Green, One Size, 3 lb Maximum Load Lmit, 4.5" Length, Swivel Head D-Ring
$0.00
Couldn't load pickup availability
Wire Sling Loop, Red, One Size, Premium Coated Stainless Steel Cable Wire, 2 lb Maximum Load Lmit
$0.00
Couldn't load pickup availability
Wire Sling with Screw Gate, Orange, One Size, Coated Stainless Steel Cable Wire, 3 lb Max Load Lmit
$0.00
Couldn't load pickup availability
Webbing Tool Connector, Green, One Size, 3 lb Maximum Load Lmit, 4.5" Length, Swivel Head D-Ring
$0.00
Couldn't load pickup availability
TigerGrip 8 Mil Nitrile Glove Orange Large
$0.00
Couldn't load pickup availability
Diamond-Textured Nitrile Gloves, Orange, 6 Mil, Large, 1,000/Case
$0.00
Couldn't load pickup availability
Diamond-Textured Nitrile Gloves, Orange, 6 Mil, X-Large, 1,000/Case
$0.00
Couldn't load pickup availability
Wyper Super Prep Towel 9 x 14"
$0.00
Couldn't load pickup availability
Butyl Windshield Tape 1/4" x 15'
$0.00
Couldn't load pickup availability
Automotive Trim Lifting Masking Tape 10mm x 10m
$0.00
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Front Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Product Description
The Werner T700000X Confined Space Kit includes the T100108 8ft Aluminum Tripod, the T410060 60-foot 3-Way Self-Retracting Lifeline with Rescue Capability (SRL-R), T510045 60-foot Material Hoist, and T200007 Pulley and Carabiner. Two T100008B Mounting Brackets attach the 60-foot 3-Way SRL-R and the 60-foot Material Hoist to any leg of the tripod. Also included is the T510080B Hoist Bracket that attaches the 60-foot Material Hoist. The Tripod extends from 58-97-inches in height for installation over openings with a maximum diameter of 42-inches when fully extended and meets the requirements of ANSI Z359.18-2017 Type A. The 3-Way SRL-R is designed for a single user with a capacity up to 310 pounds total working weight and has an aluminum housing with a lifting ratio of 6.5:1. When tested to the requirements of the ANSI Z359.14-2021 standard for Class 1 for SRLs, the 3-Way SRL-R has an average arrest force of 1,350 pounds and a maximum arrest distance of 24-inches. The hoist is capable of raising and lowering loads of up to 450 pounds. The Material Hoist has 60 feet of 3⁄16-inch diameter galvanized steel cable.• Confined Space Kit with Tripod, 60-foot 3-Way SRL-R, Bracket, Pulley, Carabiner, Hoist Bracket, and 60-foot Hoist
• Confined Space Kit includes T100108 8ft Aluminum Tripod, the T410060 60-foot 3-Way SRL-R, (2) T100008B Mounting Brackets, T510080B Hoist Bracket, T510045 60-foot Material Hoist and T200007 Pulley and carabiner
• High strength, lightweight Aluminum Tripod extends from 58-inches to 97-inches in height
• Tripod meets ANSI Z359.18-2017 Type A and OSHA regulations
• The 60-foot 3-Way SRL-R has maximum arrest distance of 24-inches
• 3-Way SRL-R meets ANSI z359.14-2021 Class 1 SRL-R and OSHA Standards
• Material Hoist is capable of raising and lowering loads of up to 450 lbs.
• Pulley is for use with up to a 3/16-inch diameter steel cable and has an 8,100 lbs. tensile breaking strength
Technical Specifications
| Item#: | 1648719 |
|---|---|
| Manufacturer Model #: | T700000X |
| Type | Confined Space Kit |
| Material | Aluminum |
| Width | 39.6 " |
| Approvals | ANSI Z359.18-2017 Type A, ANSI Z359.14-2021 Class 1 SRL-R, OSHA |
| Gate Opening | 3/4 " |
| Gate Type | Self-Closing; Self-Locking |
| Closure Type | Self-Locking Carabiner |
| Height | 96 " |
| Quantity Per Package | 1 ea. |
| UNSPSC #: | 46182301 |
| TAA Compliant: | Yes |
