Female Quick Slide Terminal, Fully Insulated, Nylon, 16 to 14 AWG, 3/16" Tab Width, Blue
(Pack of
25)
Designed for medium-gauge wires, this quick-connect slide is ideal for mechanical and industrial applications. The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection. Reusable and the fastest way to connect and disconnect two wires.
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Nylon insulation provides high-quality, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• 600V
• Female – superior clamping power even after many connections
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 2-21
Frequently Bought Together
Male Quick Slide Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Male Quick Slide Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Male Quick Slide Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Insulform Heat Shrink Tubing 22 to 18 AWG Black
Couldn't load pickup availability
Temflex™ 165 Vinyl Electrical Tape Black 3/4"
Couldn't load pickup availability
ATO/ATC Fuse 15A Light Blue
Couldn't load pickup availability
Fender Splash Shield Retainer Nylon 20mm
Couldn't load pickup availability
Phillips Truss Head Sheet Metal Screw Steel 15mm
Couldn't load pickup availability
Spot Weld Remover Drill Bit HSS 2-13/16(M8)
Couldn't load pickup availability
Wire Connector 22 to 14 AWG Blue
Couldn't load pickup availability
Winged Wire Connector 14 to 10 AWG Green
Couldn't load pickup availability
Winged Wire Connector 12 to 6 AWG Blue
Couldn't load pickup availability
Product Description
Designed for medium-gauge wires, this quick-connect slide is ideal for mechanical and industrial applications. The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection. Reusable and the fastest way to connect and disconnect two wires.• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Nylon insulation provides high-quality, chemical-resistant electrical insulation for industrial applications
• Manufactured from high-grade copper
• Annealed to flow freely under crimping pressure for best connection
• Electro-tin-plated for greatest corrosion resistance
• 600V
• Female – superior clamping power even after many connections
Technical Specifications
| Item#: | 86061 |
|---|---|
| Type | Crimp |
| Wire Gauge | 16-14 AWG |
| Tab Width | 3/16 " |
| Connection Type | Female |
| Color | Blue |
| Style | Electro-Lok Fully-Insulated Quick Slides |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.06 lb |
