Heat Shrink Tubing, 20 to 18 AWG, Clear-Seal, 1' Length, 3/16" ID Before and 0.059" ID After Shrinkage, 3:1 Shrink Ratio
(Pack of
10)
• 3:1 shrink ratio
• Dual wall design protects electrical connections from corrosion, abrasion, moisture, contaminants, breakage and wire pull-out
• Clear – allows visual examination of connection
• Remains flexible after cooling to make final wiring assembly easier
• Temperature range: –67°F to +230°F (–55°C to +110°C)
• Shrink temperature: 240°F (115°C)
• Voltage rating in USA 600V; in Canada 32V
• DOD MIL-DTL-23053/5 Class 2 Specifications
• Provides excellent strain relief for terminals and connections
• Seals wire identification markers and insulates tool handles
Wire gauge coverage is approximate due to the wide variance of wire thicknesses.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 2-4
Frequently Bought Together
Miniature Incandescent Bulb 12V 3CP
Couldn't load pickup availability
H11 Halogen Miniature Bulb 55W 12V
Couldn't load pickup availability
Miniature Incandescent Bulb 12V
Couldn't load pickup availability
Heat Shrink Tubing 20 to 14 AWG Black
Couldn't load pickup availability
Heat Shrink Tubing 24 to 22 AWG Clear
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 12 to 10 AWG Black
Couldn't load pickup availability
Bumper Fascia General Purpose Split Rivet 3/16"
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Insulform Heat Shrink Tubing 16 to 14 AWG Black
Couldn't load pickup availability
Super 33+ Series Vinyl Electrical Tape Black 3/4"
Couldn't load pickup availability
Super 33 Vinyl Electrical Tape Black 3/4" x 20'
Couldn't load pickup availability
Product Description
• 3:1 shrink ratio• Dual wall design protects electrical connections from corrosion, abrasion, moisture, contaminants, breakage and wire pull-out
• Clear – allows visual examination of connection
• Remains flexible after cooling to make final wiring assembly easier
• Temperature range: –67°F to +230°F (–55°C to +110°C)
• Shrink temperature: 240°F (115°C)
• Voltage rating in USA 600V; in Canada 32V
• DOD MIL-DTL-23053/5 Class 2 Specifications
• Provides excellent strain relief for terminals and connections
• Seals wire identification markers and insulates tool handles
Wire gauge coverage is approximate due to the wide variance of wire thicknesses.
Technical Specifications
| Item#: | P29930 |
|---|---|
| Type | Pre-Cut |
| Style | Dual Wall |
| Wire Gauge Coverage | 20-18 AWG |
| Length | 1 ft |
| Color | Clear |
| I.D. Before Shrinkage | 3/16 " |
| I.D. After Shrinkage | 0.059 " |
| Shrink Ratio | 3 to 1 |
| Wall Thickness Before Shrinkage | 0.014 " |
| Wall Thickness After Shrinkage | 0.043 " |
| Voltage Rating | 600 V |
| Temperature Rating | -67°F to 230°F/ -55°C to 110°C |
| Shrink Temperature | 240 F |
| Approvals | DOD MIL-DTL-23053/5 Class 2 Specifications |
| UNSPSC #: | 39121723 |
| TAA Compliant: | No |
| Weight: | 0.09 lb |
