Home Circuit Breakers Mid-Range Panel-Mount Circuit Breaker Type I 15A
Circuit Breakers

Mid-Range Panel-Mount Circuit Breaker Type I 15A
(Pack of 1)

Kent Automotive

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Read More
Check Availability

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov

Frequently Bought Together


Heavy-Duty Plug-In Circuit Breaker Type II 15A

Item#: 60715

Universal Plug-In Circuit Breaker Type I 5A

Item#: 92765

ATC Circuit Breaker Type I 20A 12V

Item#: 29852

MINI Fuse 15A Blue

Item#: P66002M01

ATO/ATC Fuse 15A Light Blue

Item#: P54608M01
DV_ZoomOriginal_I_9007 01.jpg

Vinyl Electrical Tape Black 3/4" x 60', 10 Rolls Per Pack

Item#: 9007 01

235 Series Glass Body Fuse 250mA

Item#: 97780

312 Series Glass Body Fuse 8A

Item#: 96063

314 Series Ceramic Body Fuse 4A

Item#: 97415

Metric Indented Hex Head Bolt with 17mm Washer

Item#: P59732

Bumper Drive Rivet Plastic 10mm Hole

Item#: P85437

Fender Splash Shield Retainer Nylon 20mm

Item#: P53958

Product Description

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Technical Specifications

Item#: 50265
Style Mid-Range Panel-Mounted Circuit Breakers
Amperage 15 A
Volts 32 DC
Approvals Ignition protected (ABYC E-9/SAE J1171)
Description Type I Automatic Reset
Type Electrical
UNSPSC #: 39121601
TAA Compliant: Yes
Weight: 0.1 lb
