Home Circuit Breakers Mid-Range Panel-Mount Circuit Breaker Type I 50A
Circuit Breakers

Mid-Range Panel-Mount Circuit Breaker, Type I Automatic Reset, 50 Amps, 30 Volts DC, Rounded Profile Body
(Pack of 1)

Item#: 50271

Kent Automotive

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Read More
Check Availability

Frequently Bought Together


Tong Style Circuit Breaker 40A

Item#: 11139

MINI Circuit Breaker Type II-25A 12V

Item#: 29849

ATC Circuit Breaker Type I 10A 12V

Item#: 29850

Miniature Incandescent Bulb 12V

Item#: P61532

Butt Connector 16 to 14 AWG Blue

Item#: P65378

180-degree Wide Beam Head Light with Side Light

Item#: 1639013

MICRO2 Series Blade Fuse 20A Yellow

Item#: 1419707

MAXI® Fuse 50A Red

Item#: P65678M01

MAXI® Fuse 40A Orange

Item#: P65677M01

Front Bumper Drive Rivet Plastic 10mm Hole

Item#: KT14285

Front Bumper Drive Rivet Plastic 7mm Hole

Item#: P85438

Front Bumper Push-Type Retainer Nylon 20mm

Item#: P15599

Product Description

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Technical Specifications

Item#: 50271
Style Mid-Range Panel-Mounted Circuit Breakers
Amperage 50 A
Volts 32 DC
Approvals Ignition protected (ABYC E-9/SAE J1171)
Description Type I Automatic Reset
Type Electrical
UNSPSC #: 39121601
TAA Compliant: Yes
Weight: 0.1 lb
