Miniature Meter Out Flow Control Regulator, 6mm Tube x M5x0.8, 150 PSI Working Pressure
(Pack of
10)
SKU:1199673 Item#: 1199673
One of the smallest in the industry, Legris miniature flow control regulators are especially adapted for precise, small sized pneumatic applications (micro-pneumatic in particular). They are specifically designed for use with small bore cylinders (short stroke / flat cylinders). Control is achieved gradually due to the extreme sensitivity of the adjustment screw, which allows exceptionally fine setting levels.
• Working temperature: 30°F to +160°F • Working pressure: 15 to 145 PSI • Sutable fluids: compressed air • Construction: – Body: glass reinforced nylon 6.6 or brass– Gripping Ring: stainless steel– Adjustment Screw: nickel-plated brass– Locking Nut: nickel-plated brass– Base: nickel-plated brass with thread sealant on tapered components
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Pipe Nipple Brass 1/4-18 x 1/4-18
$0.00
Couldn't load pickup availability
Pipe Elbow Brass 90° 1/4-18 x 1/4-18
$0.00
Couldn't load pickup availability
Pipe Hex Nipple Brass 1/4-18 x 1/4-18
$0.00
Couldn't load pickup availability
DOT Union Brass 1/4 x 1/4"
$0.00
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/4-18
$0.00
Couldn't load pickup availability
DOT Swivel Elbow Male 360° Brass 1/4 x 1/4-18
$0.00
Couldn't load pickup availability
Meter Out Flow Control Regulator, PBT Resin, 8mm x 3/8"
$0.00
Couldn't load pickup availability
Push-to-Connect Bulkhead Union, PBT Resin, 1/2 x 1/2"
$0.00
Couldn't load pickup availability
Push-to-Connect Fixed Elbow, Polyoxymethlene, 1/4 x 1/8"
$0.00
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
$0.00
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
$0.00
Couldn't load pickup availability
Rocker Molding Clip with Sealer Nylon Blue 17mm
$0.00
Couldn't load pickup availability
Product Description
One of the smallest in the industry, Legris miniature flow control regulators are especially adapted for precise, small sized pneumatic applications (micro-pneumatic in particular). They are specifically designed for use with small bore cylinders (short stroke / flat cylinders). Control is achieved gradually due to the extreme sensitivity of the adjustment screw, which allows exceptionally fine setting levels.• Working temperature: 30°F to +160°F • Working pressure: 15 to 145 PSI • Sutable fluids: compressed air • Construction: – Body: glass reinforced nylon 6.6 or brass– Gripping Ring: stainless steel– Adjustment Screw: nickel-plated brass– Locking Nut: nickel-plated brass– Base: nickel-plated brass with thread sealant on tapered components
Technical Specifications
| Item#: | 1199673 |
|---|---|
| Manufacturer Model #: | 7669 06 19 |
| Style | Flow Control Regulator |
| Configuration | Miniature Meter In |
| Tube Size | 6 mm |
| Thread Size | M5x0.8 |
| Thread Style | Metric |
| Material | Nickel-Plated Brass/PBT Resin |
| Wrench Size | 6 mm |
| Working Pressure | 150 PSI |
| Temperature Range | 32 to 140 °F |
| UNSPSC #: | 40183100 |
| TAA Compliant: | No |
