Push-to-Connect Elbow, Nickel-Plated Brass, 1/2 x 1/2", Tube x Male NPT, 280 PSI Working Pressure
(Pack of
2)
SKU:28302 Item#: 28302
Designed for pneumatic installations and conveyance of inert gases. Resin series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.
• Working Temperature: -4 to +176 °F
• Working Pressure: 280 psi
• Suitable Fluids: Compressed Air/Inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel Plated Brass
• Gripping Ring: 301 Stainless Steel
• Release Ring: Acetal Plastic
• O-Ring: NBR(Buna-N)
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Push-to-Connect Union, PBT Resin, 5/16 x 5/16"
$0.00
Couldn't load pickup availability
Push-to-Connect Straight Union, Nickel-Plated Brass, 6 x 6mm
$0.00
Couldn't load pickup availability
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 6mm x 1/4"
$0.00
Couldn't load pickup availability
Pipe Close Nipple Brass 1/4-18 x 1/4-18
$0.00
Couldn't load pickup availability
Pipe Bushing Brass 3/4-14 x 3/8-18
$0.00
Couldn't load pickup availability
Pipe Close Nipple Brass 1/2-14 x 1/2-14
$0.00
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
$0.00
Couldn't load pickup availability
Quick Disconnect Plug Brass 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 7/16 to 1"
$0.00
Couldn't load pickup availability
Push-to-Connect Union Elbow, Nickel Plated Brass, 5/32 x 5/32"
$0.00
Couldn't load pickup availability
Push-to-Connect Elbow, PBT Resin, 3/8 x 1/4"
$0.00
Couldn't load pickup availability
Push-to-Connect Connector, Nickel Plated Brass, 1/4 x 1/4"
$0.00
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Front Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Product Description
Designed for pneumatic installations and conveyance of inert gases. Resin series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.• Working Temperature: -4 to +176 °F
• Working Pressure: 280 psi
• Suitable Fluids: Compressed Air/Inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel Plated Brass
• Gripping Ring: 301 Stainless Steel
• Release Ring: Acetal Plastic
• O-Ring: NBR(Buna-N)
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.
Technical Specifications
| Item#: | 28302 |
|---|---|
| Style | Nickel-Plated Brass Push-To-Connect |
| Configuration | Male Elbow |
| Tube Size | 1/2 " |
| Thread Size | 1/2 " |
| Thread Style | NPT |
| Material | Nickel-Plated Brass |
| Wrench Size | 22 mm |
| Thread Length | 0.59 " |
| Working Pressure | 280 PSI |
| Temperature Range | -4 to +176 °F |
| UNSPSC #: | 40183100 |
| TAA Compliant: | Yes |
| Weight: | 0.28 lb |
