Push-to-Connect Plug, PBT Resin, 1/4", Tube, 150 PSI Working Pressure
(Pack of 10)

SKU:54437P Item#: 54437P

Parker Fluid Connectors Group

Designed for pneumatic installations, the LF3000 system is an essential component in a wide variety of industries. The LF3000 system is available in both fractional inch and metric tubes with NPT, UNF, BSPT, BSPP, and Metric threads.
• All items in the LF3000 range are silicone free
• Working temperature: –4°F to +175°F (–20°C to +79°C) – collet technology 3/16" tube size: 5°F to 155°F (–15°C to +68°C)
• Working pressure: Up to 290 PSI
• Suitable fluids: Compressed air
• Vacuum capability: Vacuum of 28" Hg (99% vacuum)
• Construction:
– Body: Glass-reinforced nylon 6.6
– Collar: Nylon
– Gripping ring: Stainless steel (all sizes except 3/16" tube)
– Collet: Brass (3/16" tube size only)
– D seal: Nitrile
– O-ring: Nitrile
– Base: Nickel-plated brass with thread sealant on tapered components and captive seal on parallel threads
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.

Check Availability

Quantity

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Frequently Bought Together

No product placeholder

Teflon Tape

Pipe Hex Nipple Brass 3/8-18 x 3/8-18

Pipe Street Tee Brass 1/8-27 x 1/8-27 x 1/8-27

Hose Clamp 304 SS 1/2 to 29-32"

Master O-Ring Assortment HNBR 33 Items 335Pcs

Hose Clamp 304 SS 3/4 to 1-3/4"

Push-to-Connect Bulkhead Connector, Nickel Plated Brass, 1/4 x 1/4"

Push-to-Connect Union Tee, Nickel Plated Brass, 1/2 x 1/2 x 1/2"

Push-to-Connect Extension Elbow, PBT Resin, 1/4 x 3/8"

Phillips Truss Head Sheet Metal Screw Steel 15mm

Push-Type Retainer Nylon 20mm

Front Rear Bumper Specialty Rivet 3.2mm

Product Description

Designed for pneumatic installations, the LF3000 system is an essential component in a wide variety of industries. The LF3000 system is available in both fractional inch and metric tubes with NPT, UNF, BSPT, BSPP, and Metric threads.
• All items in the LF3000 range are silicone free
• Working temperature: –4°F to +175°F (–20°C to +79°C) – collet technology 3/16" tube size: 5°F to 155°F (–15°C to +68°C)
• Working pressure: Up to 290 PSI
• Suitable fluids: Compressed air
• Vacuum capability: Vacuum of 28" Hg (99% vacuum)
• Construction:
– Body: Glass-reinforced nylon 6.6
– Collar: Nylon
– Gripping ring: Stainless steel (all sizes except 3/16" tube)
– Collet: Brass (3/16" tube size only)
– D seal: Nitrile
– O-ring: Nitrile
– Base: Nickel-plated brass with thread sealant on tapered components and captive seal on parallel threads
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.

Technical Specifications

Item#:	54437P
Manufacturer Model #:	3126 56 00 50
Configuration	Plug
Tube Size	1/4 "
Material	PBT Resin
Working Pressure	150 PSI
Temperature Range	32 to 140 °F
UNSPSC #:	40183100
TAA Compliant:	Yes
