3TR7N, Hydraulic Hose, 1 Textile Braid, 1/5 (-3) " I.D., 250' Length, 3,050 PSI, SAE 100R7
(Pack of
250)
SKU:1677595 Item#: 1677595
• Agency Rating: 100R7
• Fittings Certified: 4TA Series, 1A/Z series with sleeve and 901/902 series
• Construction:
– Inner Tube: Nylon
– Reinforcement: One textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for agriculture, horticulture, chemical transfer, foam systems, food processing, forestry delimber, general construction, general hydraulic systems , lubrication systems, marine steering, utility vehicles and pickers, rescue apparatus/tools and water jetter/sewer
Frequently Bought Together
3TR7 Hydraulic Thermoplastic Hose 0.33" x 250'
$0.00
Couldn't load pickup availability
3TR18CT Hydraulic Thermoplastic Hose 0.85" x 50'
$0.00
Couldn't load pickup availability
3TR8N Hydraulic Thermoplastic Hose 0.90" x 50'
$0.00
Couldn't load pickup availability
Spacer Ring Pink/White
$0.00
Couldn't load pickup availability
Spacer Ring Green/White
$0.00
Couldn't load pickup availability
Air Conditioning O-Ring HSN Green
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 3/8 to 7/8"
$0.00
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose
$0.00
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
$0.00
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.33" x 50'
$0.00
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 0.57" x 250'
$0.00
Couldn't load pickup availability
3TR7N Hydraulic Thermoplastic Hose 0.49" x 50'
$0.00
Couldn't load pickup availability
Product Description
• Agency Rating: 100R7• Fittings Certified: 4TA Series, 1A/Z series with sleeve and 901/902 series
• Construction:
– Inner Tube: Nylon
– Reinforcement: One textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for agriculture, horticulture, chemical transfer, foam systems, food processing, forestry delimber, general construction, general hydraulic systems , lubrication systems, marine steering, utility vehicles and pickers, rescue apparatus/tools and water jetter/sewer
Technical Specifications
| Item#: | 1677595 |
|---|---|
| Manufacturer Model #: | 3TR7N-03-250BX |
| Type | Thermoplastic Hose |
| Category / Performance | Constant Pressure |
| Industry Rating 1 | SAE 100R7 |
| Manufacturer Series Number | 3TR7N |
| Manufacturer Series Name | Synflex |
| Dash Size | -3 |
| Working Pressure | 3,050 PSI |
| Burst Pressure | 12,200 PSI |
| Inner Tube Material | Nylon |
| Hose Reinforcement | 1 Textile Braid |
| Hose Cover Material | Non-Stick Polyurethane 3TR7N Non-perforated |
| Fitting Series | 4TA Series, 1A/Z Series with Sleeve and 901/902 Series |
| Temperature | Oil Basedluids = -40F to +212F / Water Basedluids = -40F to +150 F |
| Color | Orange |
| Size | 1/5 (-3) " |
| Length | 250 ft |
| SynFlex Part No. | 3TR7N-03-250BX |
| UNSPSC #: | 40142020 |
| TAA Compliant: | Yes |
| Weight: | 15.04 lb |
