3TR8N, Hydraulic Hose, 2 Textile Braid, 3/8 (-6) " I.D., 50' Length, 4,500 PSI, SAE 100R8
(Pack of
50)
SKU:1692576 Item#: 1692576
• Agency Rating: 100R8
• Fittings Certified: 4TA Series, 1A/Z series with sleeve
• Construction:
– Inner Tube: Nylon
– Reinforcement: Double textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for air tools, cooling/misting/dust suppression, forestry delimber, general construction, general hydraulic, high pressure chemical transfer, marine steering, mobile machinery, utility vehicles, recreational vehicles and rescue tools/equipment.
Frequently Bought Together
3TR8 Hydraulic Thermoplastic Hose 0.59" x 50'
Couldn't load pickup availability
3TR18CT Hydraulic Thermoplastic Hose 0.58" x 50'
Couldn't load pickup availability
3TR7N Hydraulic Thermoplastic Hose 0.57" x 250'
Couldn't load pickup availability
08Z-BC08- Hose End (perm) 1S/1R Str Male STC
Couldn't load pickup availability
T-400-40C
Couldn't load pickup availability
06Z-BC66- Hose End (perm) 1S/1R 90 D Male STC
Couldn't load pickup availability
Miniature Clamp SS 7/32 to 5/8"
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 11/16 to 1-1/2"
Couldn't load pickup availability
Air Conditioning Slim Line Sealing Washer
Couldn't load pickup availability
Front Bumper Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Couldn't load pickup availability
Front Bumper and Radiator Support Drive Rivet
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 1.33" x 200'
Couldn't load pickup availability
3TR7N Hydraulic Thermoplastic Hose 0.57" x 50'
Couldn't load pickup availability
3TR7 Hydraulic Thermoplastic Hose 1.33" x 50'
Couldn't load pickup availability
Product Description
• Agency Rating: 100R8• Fittings Certified: 4TA Series, 1A/Z series with sleeve
• Construction:
– Inner Tube: Nylon
– Reinforcement: Double textile braid
– Cover: Polyurethane
• Temperature Range:
– Oil-based fluids: –40°F to +212°F (–40°C to +100°C)
– Water-based fluids: –40°F to +150°F (–40°C to +66°C)
• Application Notes: Recommended for air tools, cooling/misting/dust suppression, forestry delimber, general construction, general hydraulic, high pressure chemical transfer, marine steering, mobile machinery, utility vehicles, recreational vehicles and rescue tools/equipment.
Technical Specifications
| Item#: | 1692576 |
|---|---|
| Manufacturer Model #: | 3TR8N-06-050BX |
| Type | Thermoplastic Hose |
| Category / Performance | Constant Pressure |
| Industry Rating 1 | SAE 100R8 |
| Manufacturer Series Number | 3TR8N |
| Manufacturer Series Name | Synflex |
| Dash Size | -6 |
| Working Pressure | 4,500 PSI |
| Burst Pressure | 16,200 PSI |
| Inner Tube Material | Nylon |
| Hose Reinforcement | 2 Textile Braid |
| Hose Cover Material | Non-Stick Polyurethane 3TR8N Non-perforated |
| Fitting Series | 4TA Series, 1A/Z Series with Sleeve |
| Temperature | Oil Basedluids = -40F to +212F / Water Basedluids = -40F to +150 F |
| Color | Orange |
| Size | 3/8 (-6) " |
| Length | 50 ft |
| SynFlex Part No. | 3TR8N-06-050BX |
| UNSPSC #: | 40142020 |
| TAA Compliant: | Yes |
