Home Clamps + Banding Constant Torque Hose Clamp SS 4-1/4 to 5-1/8"
Clamps + Banding

Constant Torque Hose Clamp SS 4-1/4 to 5-1/8"
(Pack of 1)

Kent Automotive

• 300 Series stainless steel hose clamp with 400 Series stainless steel screw
• Heavier and stronger than standard clamps
• Eliminates cold hose leaks, saving money in lost coolant
• Patented Belleville spring assembly for automatic clamp adjustment with visual torque check
• Quadra-Lock housing design with eight screw threads engaged in band slots
• Finished band edges prevent hose damage
• Extended inner liner protects hose from extrusion and shearing through band slots
• Band width: 5/8"
• Recommended torque: 90 – 100 in./lbs.
• For medium and heavy-duty applications
• Used on Kenworth T400A and Cummins 92 engines
Reference No. is stamped on band of hose clamp.

Read More
Check Availability

Catalog page#: 7-6

Frequently Bought Together


Band-It Clamp High-Carbon Steel 2-3/4 x 5/8"

Item#: 81193
No product placeholder

TBC188

Item#: 1212924

Silicone Heater/Coolant Hose Clamp 13/16 to 1-1/2"

Item#: 88720

DOT Compression Union Brass 1/2"

Item#: 84306

Parker DOT Field Attachable - Female Connector 1/2x7/8-20

Item#: 97258P

Parker DOT Compression - Nylon Tubing Union 1/4x1/4

Item#: 84253P

One-Ear Stepless Hose Clamp 304 SS 0.228 to 0.275"

Item#: 29173

H353H Truck Hose 37/64" OD x 250'

Item#: PL64470B05

Constant Tension Hose Clamp 301 SS 5/8 to 15/16"

Item#: 60619

FLEXAIR 3/8" I.D. x 35' air hose

Item#: 1585090

Air/Water Hose Assembly 3/8" x 50' Red

Item#: 41458

Hydraulic Union 1/4-18 x 1/4-18

Item#: 86253

Radiator Grille Nut M4.2-1.41

Item#: 1513544

Bumper Drive Rivet Plastic 10mm Hole

Item#: P85437

Fender Splash Shield Retainer Nylon 20mm

Item#: P53958

Product Description

• 300 Series stainless steel hose clamp with 400 Series stainless steel screw
• Heavier and stronger than standard clamps
• Eliminates cold hose leaks, saving money in lost coolant
• Patented Belleville spring assembly for automatic clamp adjustment with visual torque check
• Quadra-Lock housing design with eight screw threads engaged in band slots
• Finished band edges prevent hose damage
• Extended inner liner protects hose from extrusion and shearing through band slots
• Band width: 5/8"
• Recommended torque: 90 – 100 in./lbs.
• For medium and heavy-duty applications
• Used on Kenworth T400A and Cummins 92 engines
Reference No. is stamped on band of hose clamp.

Technical Specifications

Item#: 97567
Category Constant Torque Hose Clamps
Applications Medium and Heavy Duty Applications
SAE Size 500
Material 300 Series Stainless Steel Clamp with 400 Series Stainless Steel Screw
Fits Hose O.D. 4-3/4 "
Size 5/8 "
Minimum Diameter 4-1/4 "
Maximum Diameter 5-1/8 "
Band Width 5/8 "
Width 5/8 "
UNSPSC #: 31162906
TAA Compliant: No
Weight: 0.286 lb
