Home Bolts DIN 6921 Hex Flange Bolt Grade 8.8 M10-1.5 x 20mm
Bolts

DIN 6921 Hex Flange Bolt, Grade 8.8, Steel, Zinc Finish, Coarse Thread, 15mm Across Flats, M10-1.5 x 20mm
(Pack of 10)

Item#: 59418

Kent Automotive

Metric Hex Head Fasteners
• Less surface pressure due to large bearing area
• Allows for a wider tolerance on the clearance hole
• Less setting of the material being clamped
• No flat washers needed
• Tensile strength 800 MPa (116,000 PSI)

Read More
Check Availability

Catalog page#: 11-40

Frequently Bought Together


Hex Cap Screw Property Class 8.8 M6-1 x 25mm

Item#: 27332

Hex Flange Bolt Grade 10.9 M10-1.25 x 16mm

Item#: 55606

DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 50mm

Item#: 59417

Hex Cap Screw Property Class 8.8 M10-1.5 x 40mm

Item#: 61272

Hex Cap Screw Property Class 8.8 M6-1 x 16mm

Item#: 27330

DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 16mm

Item#: 59411

Hex Flange Bolt Grade 8 1/4-20 x 1"

Item#: 51928

Hex Flange Bolt Grade 10.9 M6-1 x 16mm

Item#: 59720

Hex Flange Bolt Grade 10.9 M8-1.25 x 50mm

Item#: 28690

DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 30mm

Item#: 59414

DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 25mm

Item#: 59413

Hex Nut Grade 8 Steel M14-2

Item#: 80911

Front Rear Bumper Specialty Rivet 3.2mm

Item#: 1558278

Fender Splash Shield Retainer Nylon 20mm

Item#: P53958

Push-Type Retainer Nylon 20mm

Item#: P23453

Product Description

Metric Hex Head Fasteners
• Less surface pressure due to large bearing area
• Allows for a wider tolerance on the clearance hole
• Less setting of the material being clamped
• No flat washers needed
• Tensile strength 800 MPa (116,000 PSI)

Technical Specifications

Item#: 59418
Type Hex Flange Bolt
Diameter M10
Thread Pitch 1.5 mm
Thread Coarse
Length 20 mm
Finish Bright Zinc
Material Carbon Steel
Grade 8.8
Flange Diameter 22.3 mm
Head Style Hex Flange
Size M10X20 mm
Across Flats 15 mm
Specifications DIN 6921
Tensile Strength 830 MPa
UNSPSC #: 31161620
TAA Compliant: No
Weight: 0.26 lb
