Home Bolts Hex Cap Screw Grade 5 1/4-20 x 1/2"
Bolts

Hex Cap Screw, Grade 5, Steel, Zinc Finish, Coarse Thread, 5/32" Head Height, 7/16" Across Flats, 1/4-20 x 1/2"
(Pack of 100)

Item#: FA65000

FalconGrip®

• 120,000 PSI minimum tensile strength (SAE Grade 5)
• Conforms to SAE J429 material and mechanical properties
• High quality
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1

Read More
Check Availability

Catalog page#: 11-20

Frequently Bought Together


Hex Cap Screw Grade 10.9 Alloy Steel M6-1 x 20mm

Item#: 10204

Hex Cap Screw Property Class 8.8 M6-1 x 20mm

Item#: 27331

Hex Cap Screw Grade 8 1/4-20 x 1"

Item#: FA68002

Hex Cap Screw Grade 5 1/2-13 x 1"

Item#: FA65060

Hex Cap Screw Grade 8 3/8-16 x 3"

Item#: FA68040

Hex Cap Screw Grade 5 5/16-18 x 3"

Item#: FA65025

Serrated Hex Flange Nut Alloy Steel M8-1.25

Item#: 28700

DIN 6921 Hex Flange Bolt Grade 8.8 M6-1 x 16mm

Item#: 59407

SAE Flat Washer Thru-Hardened Steel 5/16"

Item#: FA88436

Hex Cap Screw Property Class 8.8 M10-1.5 x 40mm

Item#: 61272

Hex Cap Screw Property Class 8.8 M6-1 x 16mm

Item#: 27330

DIN 6921 Hex Flange Bolt Grade 8.8 M8-1.25 x 16mm

Item#: 59411

Front Bumper Push-Type Retainer Nylon 20mm

Item#: P15599

Metric Indented Hex Head Bolt with 17mm Washer

Item#: KT11580

Front Bumper and Radiator Support Drive Rivet

Item#: KT13537

Product Description

• 120,000 PSI minimum tensile strength (SAE Grade 5)
• Conforms to SAE J429 material and mechanical properties
• High quality
• Available in coarse (UNC) and fine (UNF) thread types
• Product dimensions to ANSI B18.2.1

Technical Specifications

Item#: FA65000
Style Industry Standard
Diameter 1/4 "
Thread Pitch 20
Thread Coarse
Length 1/2 "
Type Hex Cap Screw
Across Flats 7/16 "
Material Carbon Steel
Grade 5
Finish Bright Zinc
Tensile Strength 120,000 PSI
Head Style Hex
Head Height 5/32 "
Thread Form UNR
Thread Length Full
Thread Length Minimum Full
UNSPSC #: 31161501
TAA Compliant: No
Weight: 1.19 lb
