Made In USA Reducing Elbow Malleable Iron 1/2-14 x 3/8-18
(Pack of
1.0)
150 lb. Rated, Black and Galvanized
• Class 150
• Black and Galvanized
ASC Engineered Solutions™ offers the broadest line of malleable iron fitting sizes in both black and galvanized finishes. Every fitting is manufactured and tested to meet ASC's strict quality standards. All Anvil Class 150 Malleable Iron Fittings conform to ASME B16.3 and unions conform to ASME B16.39. All elbows and tees 3/8" (10 DN) and larger are 100% gas tested at a minimum of 100 PSI (6.9 bar).
• Made in USA
• Dimension: ASME B16.3
• Material: ASTM A197
• Galvanizing: ASTM A153
• Thread: ASME B1 20.1
• Pressure Rating: ASME B16.3
• Finish: Black or Galvanized
• UL Listed
• FM approved
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
PVC Large Cutter Replacement Blade
Couldn't load pickup availability
Replacement Blade for Ratch-Cut
Couldn't load pickup availability
UM4X2.5-BLU-0100
Couldn't load pickup availability
Pro Rubber Jack Hammer Air Hose Assembly 3/4" x 100'
Couldn't load pickup availability
Avagard Rubber Water Hose Assembly 5/8" x 25'
Couldn't load pickup availability
Rubber Air Hose Reel Heavy Duty Single Arm Assembly 3/8" x 50'
Couldn't load pickup availability
Pipe Union Steel Black 1/4-18 x 1/4-18
Couldn't load pickup availability
Coupling Malleable Iron 3/4-14 x 3/4-14
Couldn't load pickup availability
Coupling Malleable Iron 1/2-14 x 1/2-14
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Weatherstrip Retainer Nylon 5 x 15mm
Couldn't load pickup availability
Sheet Metal Drill Bit Alloy Steel 1/8"
Couldn't load pickup availability
Product Description
150 lb. Rated, Black and Galvanized• Class 150
• Black and Galvanized
ASC Engineered Solutions™ offers the broadest line of malleable iron fitting sizes in both black and galvanized finishes. Every fitting is manufactured and tested to meet ASC's strict quality standards. All Anvil Class 150 Malleable Iron Fittings conform to ASME B16.3 and unions conform to ASME B16.39. All elbows and tees 3/8" (10 DN) and larger are 100% gas tested at a minimum of 100 PSI (6.9 bar).
• Made in USA
• Dimension: ASME B16.3
• Material: ASTM A197
• Galvanizing: ASTM A153
• Thread: ASME B1 20.1
• Pressure Rating: ASME B16.3
• Finish: Black or Galvanized
• UL Listed
• FM approved
Technical Specifications
| Item#: | 1637817 |
|---|---|
| Fitting Type | Pipe |
| Material | Malleable Iron |
| Class | 150 lb. |
| Configuration | Reducing Elbow |
| Angle | 90 ° |
| Connection Type A x B | Female NPT x Female NPT |
| Fitting Dimension A | 1/2-14 |
| Fitting Dimension B | 3/8-18 |
| Finish | Black |
| Quantity Per Package | 1 ea. |
| UNSPSC #: | 40172806 |
| TAA Compliant: | Yes |
| Weight: | 0.23 lb |
