Wing-Type Toggle Bolt Anchor, Round Head, Steel, Zinc Finish, 7/8" Drill Size, 3/8-16 x 6"
(Pack of
25)
Toggle Bolt Assemblies
• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Masonry Anchor Assortment 700Pcs
Couldn't load pickup availability
Conical Screw Anchor Kit Plastic 101Pcs
Couldn't load pickup availability
E-Z Anchor Kit Steel 41Pcs
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M8-1.25 x 25mm
Couldn't load pickup availability
DIN 125A Flat Washer Grade 140 HV M6
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M10-1.25 x 20mm
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
Couldn't load pickup availability
Bumper Radiator and Grille Drive Rivet 7mm Hole
Couldn't load pickup availability
Hollow Wall Screw Anchor Steel Long Style 1/8"
Couldn't load pickup availability
Tamper-Proof Nail Drive Anchor Steel 1/4 x 3/4"
Couldn't load pickup availability
Hollow Wall Screw Anchor Steel Short Style #6-32
Couldn't load pickup availability
Product Description
Toggle Bolt Assemblies• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.
Technical Specifications
| Item#: | 25160 |
|---|---|
| Length | 6 " |
| Type | Wall Anchor |
| Size | 3/8X6 " |
| Diameter | 3/8 " |
| Material | Steel |
| Head Style | Round |
| Finish | Zinc |
| Thread | Coarse |
| Thread Pitch | 16 |
| Drill Size | 7/8 " |
| Anchor Size | 3/8 x 6 " |
| Tensile Proof Test Load In Concrete | 1,100 lb |
| Shear Proof Test Load | 1,100 lb |
| Bolt Size | 3/8-16 x 6 " |
| UNSPSC #: | 31162103 |
| TAA Compliant: | No |
| Weight: | 5.5 lb |
