10-32x3/8 Blind Cert Threaded Insert
(Pack of
50)
SKU:DY09820930 Item#: DY09820930
• Fasten in thin walls or blind holes
• Ideal for use in plastic-to-metal and other dissimilar materials
• Provides seal-tight applications and resists air or liquid leakage at the assembly joint
• Compressed rubber nut absorbs shock to reduce vibration
• Material: Neoprene body with a brass nut
Directions For Use:
Hollow Walls:
1. Insert in predrilled hole with flange against outer surface.
2. Part to be assembled to surface is placed against flange of fastener and secured by machine screw engaging fastener's brass nut.
3. As machine screw is tightened, neoprene body is compressed and expanded, forcing it tightly into screw threads and against surface of thin-wall material.
Solid Walls:
Follow same steps as in hollow wall fastening. As screw is tightened, body of fastener expands tightly against walls of hole, giving secure, dependable fastening.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Hex Nut Grade 8 Steel M6-1
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 12mm
$0.00
Couldn't load pickup availability
Open End Rivet Dome Head Aluminum 1/8"
$0.00
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
$0.00
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Threaded Insert for Soft Material 1/4-20
$0.00
Couldn't load pickup availability
Standard Threaded Insert M8-1.25
$0.00
Couldn't load pickup availability
Standard Threaded Insert M6-1
$0.00
Couldn't load pickup availability
Standard Threaded Insert 1/4-20
$0.00
Couldn't load pickup availability
Diamond Grip II Threaded Insert #10-32
$0.00
Couldn't load pickup availability
Diamond Grip II Threaded Insert 5/16-18
$0.00
Couldn't load pickup availability
Product Description
• Fasten in thin walls or blind holes• Ideal for use in plastic-to-metal and other dissimilar materials
• Provides seal-tight applications and resists air or liquid leakage at the assembly joint
• Compressed rubber nut absorbs shock to reduce vibration
• Material: Neoprene body with a brass nut
Directions For Use:
Hollow Walls:
1. Insert in predrilled hole with flange against outer surface.
2. Part to be assembled to surface is placed against flange of fastener and secured by machine screw engaging fastener's brass nut.
3. As machine screw is tightened, neoprene body is compressed and expanded, forcing it tightly into screw threads and against surface of thin-wall material.
Solid Walls:
Follow same steps as in hollow wall fastening. As screw is tightened, body of fastener expands tightly against walls of hole, giving secure, dependable fastening.
Technical Specifications
| Item#: | DY09820930 |
|---|---|
| Diameter | #10 |
| Thread Pitch | 32 |
| Type | Standard Threaded Inserts |
| Body Type | Knurled |
| Hole Size | 3/8 " |
| Material | Neoprene body and brass nut |
| Length | 1.051 " |
| Maximum Pull Out Load | 260 lb |
| Shank Length | 1.000 " |
| Shank Size | 0.375 " |
| Grip Range | 5/16 - 9/16 " |
| Maximum Shear Load | 500 lb |
| UNSPSC #: | 31162802 |
| TAA Compliant: | Yes |
| Weight: | 0.26 lb |
Product Restrictions
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
