Product Description
Hydraulic Hose G4H 16G4HXCTNTechnical Specifications
| Item#: | 1201424 |
|---|---|
| Manufacturer Model #: | 31050001 |
| Type | Rubber - Helical |
| Category / Performance | Low Pressure |
| Manufacturer Series Number | G4H |
| Manufacturer Series Name | G4H MegaVac |
| I.D. | 1 (-16) " |
| Hose O.D. | 1.68 " |
| Working Pressure | 200 PSI |
| Burst Pressure | 800 |
| Fitting Series | GL, MegaCrimp, Hose Clamp |
| Bend Radius | 3.0 " |
| Inner Tube Material | Nitrile - Type C |
| Hose Reinforcement | 2 Fiber Spiral Wraps with helical spiral wire |
| Hose Cover Material | Neoprene - Type A |
| Temperature | High |
| Material | Hydraulic Oil |
| Applications | Suction |
| Temperature Range | -40F to +275F constant and +300F intermittent (up to 10% of operating time |
| UNSPSC #: | 40142020 |
| TAA Compliant: | Yes |
