Bowes Quick Disconnect Nipple Steel 1/2 x 3/4"
(Pack of
1.0)
Dual guide sleeve tabs will ensure smooth collar action during connection and disconnection. “Push-Twist and Click” connection provides a positive lock when connected. Pneumatically energized seal provides an airtight seal at all working pressures. Available safety-lock ring protects against accidental disconnection while coupling is in operation. Used for air hammers and large bore air tools. Used in underground boring, power utilities and equipment rentals.
• OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories
• Locking Mechanism: Latch tabs
• Meets MIL-C-3486 for Military applications
• Operating Pressure: 300 PSI
• Coupled Burst Pressure: 3,000 PSI
• Flow: 250 CFM
• Dixon: N-Series
• Bowes: 51000 Series
• Use of band-style clamps, crimped ferrules or interlocking clamps is suggested (see specific fitting recommendations on individual hose pages)
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Tru-Flate Safety Push-Button Safety Coupler 1/2" Body x 3/8" MNPT
Couldn't load pickup availability
Quick Disconnect Plug Brass 1/4" x 1/4-18
Couldn't load pickup availability
Quick Disconnect Coupler Steel 1/2" x 3/4-14
Couldn't load pickup availability
Stainless Steel Standard Industrial Safety Push-Button Safety Coupler 1/2" Body x 3/8" FNPT
Couldn't load pickup availability
Air Hose Ferrule Brass 7/8"
Couldn't load pickup availability
Tru-Flate Safety Push-Button Safety Coupler 1/4" Body x 3/8" FNPT
Couldn't load pickup availability
Avagard Poly Air Hose Assembly 1/4" x 100'
Couldn't load pickup availability
OilShield Rubber Air Hose Assembly 3/8" x 10'
Couldn't load pickup availability
Pro Rubber Air Hose Assembly 3/4" x 100'
Couldn't load pickup availability
Barb-Lok Hose End 1/4" (-4) x 3/8-18 (-6)
Couldn't load pickup availability
Barb-Lok Hose End 1/4" (-4) x 1/8-27 (-2)
Couldn't load pickup availability
Barb-Lok Hose End 1/2" (-8) x 1/2-14 (-8)
Couldn't load pickup availability
Wheel Flare Molding Clip with Sealer Nylon
Couldn't load pickup availability
Bumper Fascia Flares/Air Dam Push-Type Retainer
Couldn't load pickup availability
Wire Stripper-Cutter 6" Stainless Steel Jaws
Couldn't load pickup availability
Product Description
Dual guide sleeve tabs will ensure smooth collar action during connection and disconnection. “Push-Twist and Click” connection provides a positive lock when connected. Pneumatically energized seal provides an airtight seal at all working pressures. Available safety-lock ring protects against accidental disconnection while coupling is in operation. Used for air hammers and large bore air tools. Used in underground boring, power utilities and equipment rentals.• OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories
• Locking Mechanism: Latch tabs
• Meets MIL-C-3486 for Military applications
• Operating Pressure: 300 PSI
• Coupled Burst Pressure: 3,000 PSI
• Flow: 250 CFM
• Dixon: N-Series
• Bowes: 51000 Series
• Use of band-style clamps, crimped ferrules or interlocking clamps is suggested (see specific fitting recommendations on individual hose pages)
Technical Specifications
| Item#: | 20924 |
|---|---|
| Description | Industrial Quick Disconnect |
| Type | Nipple, Safety-Lock |
| Style | Bowes |
| Body Size | 1/2 " |
| Thread Style | Barb Safety Lock |
| Working Pressure | 500 PSI |
| Material | Steel |
| Hose I.D. | 3/4 " |
| Length | 4.77 " |
| Seal Material | Nitrile (Buna-N) |
| Standards | MIL-C-3486; A-A-50431A |
| Dixon Number | N4S6-LS |
| Hose Barb Size | 3/4 " |
| Locking Mechanism | Latch Tabs |
| Flow | 204 ft³/min |
| UNSPSC #: | 27131613 |
| TAA Compliant: | Yes |
| Weight: | 0.5 lb |
