FLQ Series Midget Fuse, 20 Amps, 500 Volts, Time Delay, 13/32" Diameter, 1-1/2" Length
(Pack of
1)
SKU:16441 Item#: 16441
• Voltage rating: 500V AC• UL and CSA 500V ratings permit use on 480V AC circuits• Interrupting rating: 10,000A rms symmetrical• 1-1/2" long, 13/32" dia.
• Provide excellent supplemental protection of control power transformers, solenoids and circuits with high-inrush currents
• Also provide supplemental protection to small motors
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer -
www.P65Warnings.ca.gov
Frequently Bought Together
Miniature Incandescent Bulb 12V 36CP
$0.00
Couldn't load pickup availability
Miniature Incandescent Bulb 12V 37CP
$0.00
Couldn't load pickup availability
Super 33+ Series Vinyl Electrical Tape Black 3/4"
$0.00
Couldn't load pickup availability
Low-Profile MINI Fuse 5A Tan
$0.00
Couldn't load pickup availability
MINI Fuse 30A Green
$0.00
Couldn't load pickup availability
MICRO2 Series Blade Fuse 15A Blue
$0.00
Couldn't load pickup availability
523 Series Midget Fuse 1A
$0.00
Couldn't load pickup availability
523 Series Midget Fuse 0.6A
$0.00
Couldn't load pickup availability
CCMR Series Class CC Fuse 5A
$0.00
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
$0.00
Couldn't load pickup availability
Product Description
• Voltage rating: 500V AC• UL and CSA 500V ratings permit use on 480V AC circuits• Interrupting rating: 10,000A rms symmetrical• 1-1/2" long, 13/32" dia.• Provide excellent supplemental protection of control power transformers, solenoids and circuits with high-inrush currents
• Also provide supplemental protection to small motors
Technical Specifications
| Item#: | 16441 |
|---|---|
| Style | FLQ Time-Delay Midget Fuses |
| Amperage | 20 A |
| Diameter | 13/32 " |
| Length | 1-1/2 " |
| Rating | 500olt AC V |
| Approvals | UL, CSA |
| Type | Fuses |
| Bussman Number | FNQ-20 |
| Littelfuse Fuse Type | FLQ-20 |
| UNSPSC #: | 39121627 |
| TAA Compliant: | Yes |
| Weight: | 0.02 lb |
