H.D. Plain Trolley, 2 Ton Cpcty
(Pack of
1)
SKU:ZZ24161H25 Item#: ZZ24161H25
Designed for demanding industrial environments, the PT Series is built with heavier gauge steel for increased durability. Larger diameter bearings and steel wheels provide smoother movement on a variety of beams. Available up to 10 ton capacities.
• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Built-in bumper guards increase user safety and extend the life of the trolley
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
Frequently Bought Together
Front Fender Liner Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Product Description
Designed for demanding industrial environments, the PT Series is built with heavier gauge steel for increased durability. Larger diameter bearings and steel wheels provide smoother movement on a variety of beams. Available up to 10 ton capacities.• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Built-in bumper guards increase user safety and extend the life of the trolley
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
Technical Specifications
| Item#: | ZZ24161H25 |
|---|---|
| Manufacturer Model #: | 2-PT |
| Style | Manual |
| Series | PT |
| Load Capacity | 4,400 lb |
| Beam Flange Width | 3-1/4 - 8 " |
| Beam Height | 4 - 19 " |
| Curve Radius Min. | 43 " |
| UNSPSC #: | 27000000 |
| TAA Compliant: | No |
