Mid-Range Panel-Mount Circuit Breaker, Type III Manual Reset, 15 Amps, 30 Volts DC, Rounded Profile Body
(Pack of
1)
SKU:50257 Item#: 50257
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Frequently Bought Together
Mid-Range Panel-Mount Circuit Breaker Type I 40A
$0.00
Couldn't load pickup availability
Computer-Safe Automotive Logic Probe 18 AWG 6'
$0.00
Couldn't load pickup availability
Post-Style Circuit Breaker without Bracket 15A 12V
$0.00
Couldn't load pickup availability
Rechargeable Penlight Flashlight
$0.00
Couldn't load pickup availability
Lithium Coin Cell Battery #2032 3V
$0.00
Couldn't load pickup availability
Energizer® AA Alkaline Battery 1.5V
$0.00
Couldn't load pickup availability
MINI Fuse 5A Tan
$0.00
Couldn't load pickup availability
JCASE High Amp Fuse 30A Pink
$0.00
Couldn't load pickup availability
MCaseâ„¢ Cartridge Fuse 25A Clear
$0.00
Couldn't load pickup availability
Front Rear Bumper Specialty Rivet 3.2mm
$0.00
Couldn't load pickup availability
Radiator Grille Nut M4.2-1.41
$0.00
Couldn't load pickup availability
Fender Splash Shield Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Product Description
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Technical Specifications
| Item#: | 50257 |
|---|---|
| Style | Mid-Range Panel-Mounted Circuit Breakers |
| Amperage | 15 A |
| Volts | 32 DC |
| Approvals | Ignition protected (ABYC E-9/SAE J1171) |
| Description | Type III Manual Reset |
| Type | Electrical |
| UNSPSC #: | 39121601 |
| TAA Compliant: | Yes |
| Weight: | 0.11 lb |
