Industrial Quick Disconnect Coupler, Brass, Thor, 300PSI, Female NPTF, 1/2" Body Size, 3/4-14 Thread Size
(Pack of
1)
SKU:20931 Item#: 20931
Interlocking finger connection with single or dual locking sleeves for maximum security. “Push-Twist and Click” connection provides a positive lock when connected. Used for air, water and nitrogen. Used by refineries. OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories.
• OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories
• Locking mechanism: Latch tabs
• Operating pressure: 300 PSI
• Coupled burst pressure: 4,800 PSI
• Flow: 250 CFM
• Locking mechanism: Latch fingers
• Dixon P-Series
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Quick Disconnect Plug Steel 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Universal Air Coupler Brass 1/4" x 3/8-18
$0.00
Couldn't load pickup availability
Push-Button Air Coupler Plug Steel 1/4" x 3/8-18
$0.00
Couldn't load pickup availability
Air Hose Ferrule Brass 21/32"
$0.00
Couldn't load pickup availability
Hose End Brass 3/8" x 1/4-18
$0.00
Couldn't load pickup availability
Quick Disconnect Plug Brass 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose
$0.00
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/8-27
$0.00
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
$0.00
Couldn't load pickup availability
Quick Disconnect Plug Steel 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Air Hose Ferrule Brass 21/32"
$0.00
Couldn't load pickup availability
Hose End Brass 3/8" x 1/4-18
$0.00
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
$0.00
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
$0.00
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Product Description
Interlocking finger connection with single or dual locking sleeves for maximum security. “Push-Twist and Click” connection provides a positive lock when connected. Used for air, water and nitrogen. Used by refineries. OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories.• OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection – see Accessories
• Locking mechanism: Latch tabs
• Operating pressure: 300 PSI
• Coupled burst pressure: 4,800 PSI
• Flow: 250 CFM
• Locking mechanism: Latch fingers
• Dixon P-Series
Technical Specifications
| Item#: | 20931 |
|---|---|
| Manufacturer Model #: | 4PF6-B |
| Description | Industrial Quick Disconnect |
| Type | Coupler |
| Style | Thor |
| Body Size | 1/2 " |
| Thread Style | Female NPTF |
| Thread Size | 3/4-14 |
| Working Pressure | 300 PSI |
| Material | Brass |
| Length | 2.75 " |
| Seal Material | Nitrile (Buna-N) |
| Hex Size | 1-1/4 " |
| Dixon Number | 4PF6-B |
| Locking Mechanism | Latch Fingers |
| Flow | 255 ft³/min |
| UNSPSC #: | 27131613 |
| TAA Compliant: | Yes |
| Weight: | 0.7 lb |
