Terminal Crimping Tool with Interchangeable Die, 22-10 AWG, Full Cycle Ratchet, Suitable for Insulated Terminals
(Pack of
1)
SKU:95109 Item#: 95109
• Professional tool incorporating a single frame with several interchangeable dies
• Full cycle ratchet with safety release
• High-quality electrical and mechanical crimps are made simultaneously
• Crimps meet or exceed industry standards
• Assures a positive mechanical and electrical crimp and ease of use
• Crimping dies can be easily switched with two screws
The die will slide out towards the front of the frame simply by loosening the two socket head screws and removing them.
To replace the die1. Simply extend the frame to its full open position.2. Close the frame approximately halfway. 3. Insert the die into the frame until it stops. All dies can be inserted only one way for the tool to close properly.4. Tighten the screws approximately halfway. 5. Close the frame to press the dies against each other. This helps to align the dies in the frame.6. Finish tightening the screws. 7. Frame and tool are complete and ready for use.
Frequently Bought Together
Super Magna-Crimp Ratcheted Crimping Tool For 26 - 6 Gauge
$0.00
Couldn't load pickup availability
Terminal Crimp Tool with Die RG58/RG62
$0.00
Couldn't load pickup availability
Crimping Tool Forged 22-10 AWG
$0.00
Couldn't load pickup availability
2GA/25mm Replacement Die
$0.00
Couldn't load pickup availability
Comfort Grip Ergonomic Safety Wire Stipper Cutter And Cable Tie Cutter
$0.00
Couldn't load pickup availability
Crimping Tool Pin and Socket 12-24 AWG
$0.00
Couldn't load pickup availability
Cartridge Roll and Spiral Point Mandrel 1"
$0.00
Couldn't load pickup availability
Spot Sanding Pen Glass Fiber Cartridge Refill
$0.00
Couldn't load pickup availability
Pneumatic Bristle Surface Preparation Tool 12"
$0.00
Couldn't load pickup availability
Molding Clip with Sealer Nylon White 11.5 x 21
$0.00
Couldn't load pickup availability
Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Radiator Grille Nut M4.2-1.41
$0.00
Couldn't load pickup availability
Alu-Master 8-Way Torpedo Level
$0.00
Couldn't load pickup availability
2.1 Round Head Ratchet 3/8 Drive 168 Tooth
$0.00
Couldn't load pickup availability
57Pc Torsion Impact Bit Master Set
$0.00
Couldn't load pickup availability
Product Description
• Professional tool incorporating a single frame with several interchangeable dies• Full cycle ratchet with safety release
• High-quality electrical and mechanical crimps are made simultaneously
• Crimps meet or exceed industry standards
• Assures a positive mechanical and electrical crimp and ease of use
• Crimping dies can be easily switched with two screws
The die will slide out towards the front of the frame simply by loosening the two socket head screws and removing them.
To replace the die1. Simply extend the frame to its full open position.2. Close the frame approximately halfway. 3. Insert the die into the frame until it stops. All dies can be inserted only one way for the tool to close properly.4. Tighten the screws approximately halfway. 5. Close the frame to press the dies against each other. This helps to align the dies in the frame.6. Finish tightening the screws. 7. Frame and tool are complete and ready for use.
Technical Specifications
| Item#: | 95109 |
|---|---|
| Type | Crimping Tool |
| Style | Terminal Connector Crimping System |
| Crimp Range | 22-10 AWG |
| Description | Tool with 95103 Die |
| UNSPSC #: | 27111500 |
| TAA Compliant: | Yes |
| Weight: | 1.85 lb |
