H039 Weatherhead Suction/Return Line Hose, CPE Inner Tube, Neoprene Steel Helix, Black, 150PSI, 1-1/2" (-24) ID
(Pack of
50)
SKU:64628 24 Item#: 64628 24
• Agency Ratings: SAE 100R4AT
• Fittings Certified: Z-Series
• Agency Approvals: MSHA, Marine Application J1942/1 Hydraulic Service, ABS
• Construction:
– Inner Tube: CPE
– Reinforcement: One helical cable wire between two textile layers plus one fabric braid
– Cover: Neoprene
• Temperature Range:
– Petroleum-based fluids: –40°F to +275°F (–40°C to +135°C)
• Application Note: Hydraulic suction hose
Consists of no more than two pieces totaling 50 feet (±10%)
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
Mill Suction and Discharge Hose 2" White
$0.00
Couldn't load pickup availability
Spiraflex 1600 Suction/Discharge Hose 3" Green
$0.00
Couldn't load pickup availability
Weatherhead Suction/Return Line Hose 1" Black
$0.00
Couldn't load pickup availability
Rubber Air Hose Whip / Snubber 3/8" x 5'
$0.00
Couldn't load pickup availability
Avagard Rubber Air Hose Assembly 3/8" x 50'
$0.00
Couldn't load pickup availability
Lead-in Hose Assembly 3/8" Blue
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 1-9/16 to 2-1/2"
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 9/16 to 1-1/4"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose assembly w/ Industrial safety coupler
$0.00
Couldn't load pickup availability
Push-Type Retainer Nylon 16 x 19mm
$0.00
Couldn't load pickup availability
Bumper Fascia General Purpose Split Rivet 3/16"
$0.00
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
$0.00
Couldn't load pickup availability
Product Description
• Agency Ratings: SAE 100R4AT• Fittings Certified: Z-Series
• Agency Approvals: MSHA, Marine Application J1942/1 Hydraulic Service, ABS
• Construction:
– Inner Tube: CPE
– Reinforcement: One helical cable wire between two textile layers plus one fabric braid
– Cover: Neoprene
• Temperature Range:
– Petroleum-based fluids: –40°F to +275°F (–40°C to +135°C)
• Application Note: Hydraulic suction hose
Consists of no more than two pieces totaling 50 feet (±10%)
Technical Specifications
| Item#: | 64628 24 |
|---|---|
| Type | Suction and Discharge |
| Industry Rating 1 | SAE 100R4 |
| Manufacturer Series Number | H039 |
| Manufacturer Series Name | Weatherhead |
| I.D. | 1-1/2 (-24) " |
| Working Pressure | 150 PSI |
| Minimum Bend Radius | 5 " |
| Inner Tube Material | CPE |
| Hose Cover Material | Neoprene |
| Fitting Series | Z-Series |
| Temperature | -40F to +275F |
| Color | Black |
| Size | 1-1/2 (-24) |
| Mercury Vacuum (Inches) | 25 |
| UNSPSC #: | 40142000 |
| TAA Compliant: | Yes |
| Weight: | 45.0 lb |
Product Restrictions
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
