Combination Drill-Tap, M1 High Speed Steel, 118° Split Point, M8-1.25, 0.69" Tap Length, 3.68" Overall Length
(Pack of
1)
• Eliminates the need for using a twist drill and a separate tap to achieve a tapped hole
• 118° spiral point
• Three positive driving flats on the shank
• Neck is reduced below minor diameter for added clearance
• Made of M1 high-speed steel
• Made in USA
• Ideal for cordless drills; can be used in hand-held or stationary drills for tapping through holes
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Frequently Bought Together
Cryo-Drap #6-32 Drill & Tap Combo, 135o Split Point, W/Flats
Couldn't load pickup availability
HSS Combination Drill-Tap M7
Couldn't load pickup availability
Combination Drill-Tap Set #6 to 1/2"
Couldn't load pickup availability
Cryobit 1/8" Dia. Maintenance Drill Bit , 135o Split Point, No Flats
Couldn't load pickup availability
Spot Weld Remover Drill Bit 5/16" (M8)
Couldn't load pickup availability
Zirconium Grain Locking Grinding Disc 2"
Couldn't load pickup availability
Front Fender Liner Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Carbon Steel Replacement Hand Tap M12 x 1.75
Couldn't load pickup availability
4-Flute HSS Taper Hand Tap 3/8-16
Couldn't load pickup availability
3-Flute HSS Taper Hand Tap 3-48
Couldn't load pickup availability
Razor Blade Single Edge w/Notch
Couldn't load pickup availability
0.5 HP Reciprocating Air Saw
Couldn't load pickup availability
Pneumatic Impact Wrench, 1/2 Drive Max Torque 730 lbs
Couldn't load pickup availability
Product Description
• Eliminates the need for using a twist drill and a separate tap to achieve a tapped hole• 118° spiral point
• Three positive driving flats on the shank
• Neck is reduced below minor diameter for added clearance
• Made of M1 high-speed steel
• Made in USA
• Ideal for cordless drills; can be used in hand-held or stationary drills for tapping through holes
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Technical Specifications
| Item#: | 27383 |
|---|---|
| Type | Combination Drill Tap |
| Point | 118° Split |
| Diameter | M8 |
| Pitch | 1.25 mm |
| Tap Length | 0.6900 " |
| Material Thickness | 5/8 " |
| Material | HSS |
| Overall Length | 3.68 " |
| UNSPSC #: | 23241615 |
| TAA Compliant: | Yes |
| Weight: | 0.05 lb |
