Retaining Ring, Internal, Steel, Black Phosphate Finish, 9/16" Shaft Diameter
(Pack of
50)
SKU:11223 Item#: 11223
• Replaces pins, washers, threaded sections, collars and machine shoulders
• Manufactured from SAE 1065-1090 high carbon spring steel
• Heat-treated and oil-dipped
• Conforms to NAS 669 and 670 and MS 16624 through MS 1116634 specifications
• Maximum operating temperature: 480°F (249°C)
Retaining RingsRetaining rings are precision-engineered components placed on shafts or in bores, which provide a shoulder that accurately positions, locates or retains other parts of an assembly. They save time and labor, and decrease maintenance costs. Our rigid quality-control program provides you with the finest rings on the market today.
NOTE: See actual size Internal Type Retaining Ring illustrations.
Frequently Bought Together
Hex Nut Grade 8 Steel M10-1.5
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 12mm
$0.00
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M6-1 x 25mm
$0.00
Couldn't load pickup availability
Retaining Ring Internal Steel 3"
$0.00
Couldn't load pickup availability
Retaining Ring Internal Steel 16mm
$0.00
Couldn't load pickup availability
Retaining Ring Internal Steel 2-1/16"
$0.00
Couldn't load pickup availability
Retaining Ring Assortment External 460Pcs
$0.00
Couldn't load pickup availability
Retaining Ring Assortment E-Type 355Pcs
$0.00
Couldn't load pickup availability
Portable Retaining Ring Kit External 75Pcs
$0.00
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
$0.00
Couldn't load pickup availability
Front/Rear Bumper Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Bumper Clip Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Product Description
• Replaces pins, washers, threaded sections, collars and machine shoulders• Manufactured from SAE 1065-1090 high carbon spring steel
• Heat-treated and oil-dipped
• Conforms to NAS 669 and 670 and MS 16624 through MS 1116634 specifications
• Maximum operating temperature: 480°F (249°C)
Retaining RingsRetaining rings are precision-engineered components placed on shafts or in bores, which provide a shoulder that accurately positions, locates or retains other parts of an assembly. They save time and labor, and decrease maintenance costs. Our rigid quality-control program provides you with the finest rings on the market today.
NOTE: See actual size Internal Type Retaining Ring illustrations.
Technical Specifications
| Item#: | 11223 |
|---|---|
| Shaft Diameter | 9/16 " |
| Ring Clearance | .28 " |
| Ring Thickness | .035 " |
| Groove Diameter | .596 " |
| Groove Width | .039 " |
| Finish | Black Phosphate |
| Type | Internal Type Retaining Ring |
| Material | Carbon Steel |
| Size | 9/16 " |
| UNSPSC #: | 31163202 |
| TAA Compliant: | Yes |
| Weight: | 0.06 lb |
