Tru-Flate Safety Push-Button Safety Coupler 3/8" Body x 3/8" MNPT
(Pack of
1)
SKU:1489990 Item#: 1489990
The prevoS1 coupling meets the top level of quality standards required in the professional industry. Prevost prevoS1 couplers are synonymous with top of the line quality, extended service life, advanced technology, safety and efficiency. The prevoS1 couplings are unrivalled in the market with patent and protected technology.
• Polymer body material: anti-scratch body material also allows user to create a firm grip on the coupling
• One push control to decompress the system and disconnect in complete safety: eliminates hose whip to protect the user, surrounding tools and equipment (ISO 4414 standard)
• Quick and effortless coupling: easy to connect, with no risk of damaging the internal mechanism
• Swivel body creates a quick assembly and optimal positioning: cost savings from increased productivity and decreased labor requirements
• Compact and lightweight coupling for maximum user comfort when handling repetitively
• Provides accuracy and increases work station efficiency - functionally designed to allow a natural grip and easy handling
• Anti-static: conducts electricity to avoid problems related to static electricity (ex. dust attracted to paint/polish or electronic work surfaces)
• Resistant to abrasion, vibrations, corrosion, impacts and crushing: reinforced polymer body is capable of withstanding the harsh conditions frequently found in production environments
• Color coded buttons make the wide selection of international profiles easy to identify: this system reduces the risk of connection errors which may cause damages or accidents
• ATEX classification 1 and 2 (gas) and 21 and 22 (dust)
• Silicone free
• Anti-static construction
• Polymer body
• Nitrile NBR gasket
• Pressure range: 29 to 174 psi (not suitable for vacuum)
• Temperature: +5°F to +158°F (-15°C to 70°C)
• Other components: steel or aluminum with RoHS compliant anti-corrosion treatment
Applications
• All connections
• Assembly lines (automotive, household appliances, etc.)
• Mechanical manufacturing, machining workshops
• Paper and printing industries
• Automotive repairs
• Textile industries
• Wood and plastics industries
• All work on fragile products
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 10-41
Frequently Bought Together
Push-Button Air Coupler Steel 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Push-Button Air Coupler Steel 1/4" x 3/8-18
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/4" Body x 1/4" FNPT
$0.00
Couldn't load pickup availability
Trash Can Liner Low Density 24 x 32"
$0.00
Couldn't load pickup availability
Trash Can Liner Low Density 43 x 47"
$0.00
Couldn't load pickup availability
Trash Can Liner High Density 43 x 48"
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/4" Body x 1/4" MNPT
$0.00
Couldn't load pickup availability
Tru-Flate Safety Push-Button Safety Coupler 1/4" Body x 1/4" MNPT
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 3/8" Body x 3/8" MNPT
$0.00
Couldn't load pickup availability
Push-Button Air Coupler Steel 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Push-Button Air Coupler Steel 1/4" x 3/8-18
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/4" Body x 1/4" FNPT
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 9/16 to 1-1/4"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose
$0.00
Couldn't load pickup availability
Quick Disconnect Coupler Brass 1/4" x 1/4-18
$0.00
Couldn't load pickup availability
Push-Button Air Coupler Steel 1/4" x 3/8-18
$0.00
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/4" Body x 1/4" FNPT
$0.00
Couldn't load pickup availability
Monsoon Hose Nozzle 3/4"
$0.00
Couldn't load pickup availability
High Flow Safety Push-Button Safety Coupler 3/8" Body x 1/4" FNPT
$0.00
Couldn't load pickup availability
Blind Rivet Nut Insert Riv-Float Short #10-24
$0.00
Couldn't load pickup availability
1101 Aqueous Parts Cleaning Solution
$0.00
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
$0.00
Couldn't load pickup availability
Inner Fender Shield Attaching Clip Nylon Black
$0.00
Couldn't load pickup availability
Front Fender Liner Push-Type Retainer Nylon 20mm
$0.00
Couldn't load pickup availability
Product Description
The prevoS1 coupling meets the top level of quality standards required in the professional industry. Prevost prevoS1 couplers are synonymous with top of the line quality, extended service life, advanced technology, safety and efficiency. The prevoS1 couplings are unrivalled in the market with patent and protected technology.• Polymer body material: anti-scratch body material also allows user to create a firm grip on the coupling
• One push control to decompress the system and disconnect in complete safety: eliminates hose whip to protect the user, surrounding tools and equipment (ISO 4414 standard)
• Quick and effortless coupling: easy to connect, with no risk of damaging the internal mechanism
• Swivel body creates a quick assembly and optimal positioning: cost savings from increased productivity and decreased labor requirements
• Compact and lightweight coupling for maximum user comfort when handling repetitively
• Provides accuracy and increases work station efficiency - functionally designed to allow a natural grip and easy handling
• Anti-static: conducts electricity to avoid problems related to static electricity (ex. dust attracted to paint/polish or electronic work surfaces)
• Resistant to abrasion, vibrations, corrosion, impacts and crushing: reinforced polymer body is capable of withstanding the harsh conditions frequently found in production environments
• Color coded buttons make the wide selection of international profiles easy to identify: this system reduces the risk of connection errors which may cause damages or accidents
• ATEX classification 1 and 2 (gas) and 21 and 22 (dust)
• Silicone free
• Anti-static construction
• Polymer body
• Nitrile NBR gasket
• Pressure range: 29 to 174 psi (not suitable for vacuum)
• Temperature: +5°F to +158°F (-15°C to 70°C)
• Other components: steel or aluminum with RoHS compliant anti-corrosion treatment
Applications
• All connections
• Assembly lines (automotive, household appliances, etc.)
• Mechanical manufacturing, machining workshops
• Paper and printing industries
• Automotive repairs
• Textile industries
• Wood and plastics industries
• All work on fragile products
Technical Specifications
| Item#: | 1489990 |
|---|---|
| Manufacturer Model #: | USI 081252 |
| Description | Safety Push-Button Coupler |
| Style | Tru-Flate |
| Body Size | 3/8 " |
| Thread Style | Male NPT |
| Thread Size | 3/8-18 " |
| Working Pressure | 29 to 174 PSI |
| Material | Steel with Composite Body |
| Seal Material | Nitrile NBR o-ring |
| Standards | ISO 4414 |
| Flow | 81 SCFM |
| UNSPSC #: | 27131613 |
| TAA Compliant: | Yes |
| Weight: | 0.36 lb |
Product Restrictions
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
