Cryocut 3/8" Body Dia. 82o Angle Countersink, 3-Flute, 1/4" Shank Size, 1-3/4" Overall Length, 7/8" Shank Length
(Pack of
1)
SKU:DY80850108 Item#: DY80850108
• Three-flute center reamers cut countersinks and recesses for extisting holes
• Cryophase™ treatment extends the wear resistance and useful life of these high speed steel countersinks
• 82°, 90° and 100° angles cover countersink requirements for most common fastener head styles
Specifications
• Material: High Speed Steel
• Hardness: 64-66Rc
• Cryophase™: Thermal cycling cryogenic treatment
Applications
• 82° - commonly found on oval countersunk head machine screws, flat head tapping screws, oval trim head tapping screws, socket flat head cap screws and countersunk head plow bolts
• 90° - Commonly found on oval head rivets and flat head countersunk rivets
• 100° - Commonly found on flat head blind rivets, self-plugging rivets, flush head drive pin rivets, close tolerance flat countersunk head machine screws, and flat head tapping screws
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Frequently Bought Together
Chatterless Countersink 82° Six Flute 5/8"
Couldn't load pickup availability
Cryocut 5/8" Body Dia. 82o Angle Countersink, 3-Flute
Couldn't load pickup availability
Cryocut 3/4" Body Dia. 82o Angle Countersink, 3-Flute
Couldn't load pickup availability
Chatterless Countersink 82° Single Flute 3/8"
Couldn't load pickup availability
Cryocut 1/8" Body Dia. 82o Angle Countersink, 1-Flute
Couldn't load pickup availability
Countersink 82° Single Flute 9/16"
Couldn't load pickup availability
Zirconium Grain Locking Grinding Disc 2"
Couldn't load pickup availability
Spot Weld Remover Drill Bit HSS 2-3/4" (M8)
Couldn't load pickup availability
Cryobit 1/8" Dia. Maintenance Drill Bit , 135o Split Point, No Flats
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Front Fender Liner Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
Couldn't load pickup availability
Twist-On Abrasive Disc 2"
Couldn't load pickup availability
Sheet Metal Drill Bit Alloy Steel 3/16"
Couldn't load pickup availability
Interchangeable Hex Bit Set 24Pc SAE
Couldn't load pickup availability
Product Description
• Three-flute center reamers cut countersinks and recesses for extisting holes• Cryophase™ treatment extends the wear resistance and useful life of these high speed steel countersinks
• 82°, 90° and 100° angles cover countersink requirements for most common fastener head styles
Specifications
• Material: High Speed Steel
• Hardness: 64-66Rc
• Cryophase™: Thermal cycling cryogenic treatment
Applications
• 82° - commonly found on oval countersunk head machine screws, flat head tapping screws, oval trim head tapping screws, socket flat head cap screws and countersunk head plow bolts
• 90° - Commonly found on oval head rivets and flat head countersunk rivets
• 100° - Commonly found on flat head blind rivets, self-plugging rivets, flush head drive pin rivets, close tolerance flat countersunk head machine screws, and flat head tapping screws
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Technical Specifications
| Item#: | DY80850108 |
|---|---|
| Type | Countersink |
| Body Diameter | 3/8 " |
| Flutes | Three |
| Included Angle | 82 ° |
| Shank Size | 1/4 " |
| Shank Length | 7/8 " |
| Overall Length | 1-3/4 " |
| For Screw Size | No. 4 - No. 8 |
| Centerline Angle | 41 ° |
| UNSPSC #: | 23241603 |
| TAA Compliant: | No |
| Weight: | 0.03 lb |
