4S Series Crimp-On Elbow, Carbon Steel, Split Flange 30°, SAE 61, 1-1/4 (-20) x 2.38" (-24)
(Pack of
1)
SKU:1543099 Item#: 1543099
Compatible Hoses
4S: H430 (-12 through -32); H430R (-12 through -32); EC525 (-12 through -32); H471 (-12 through -24); H464 (-12 through -32); EC810 (-12, -16)
6S: H471 (-32); EC810 (-20 through -32)
These fittings are designed to be crimped in Weatherhead® Coll-O-Crimp® machines.
