A510022 10K Mega-Swivel Anchor with Straight Loop Attachment Bolt
(Pack of
1.0)
The Werner 10K Mega-Swivel with Straight Loop Insert Bolt attaches to the Werner Straight Loop Insert that was cast-in place during construction of the surface. The Mega-Swivel is made of steel and plated for corrosion resistance. Includes 5/8 inch bolt and lock washer. The Mega-Swivel design allows full range of motion.
• Robust steel design with 360 degree swivel of the forged D-ring
• Includes 5/8 inch x 2-1/2 inch bolt, internal tooth lock washer
• Minimum Breaking Strength (MBS):10,000 lbs.
Frequently Bought Together
Titan Anchorage Connector
Couldn't load pickup availability
L400002 12in Cast-in-Place PVC Sleeve
Couldn't load pickup availability
Squids 3780 Power Tool Trap
Couldn't load pickup availability
R431006-SR 6ft Bantam Twinleg Self-Retracting Lifeline w/Steel Rebar
Couldn't load pickup availability
LITEFIT H312005 Standard (Back D-Ring) Harness (XXL)
Couldn't load pickup availability
ProFormâ„¢ Switchpoint H062145 Climbing/Construction Harness, Tongue Buckle Legs
Couldn't load pickup availability
CL1 Checklite Safety Glasses
Couldn't load pickup availability
Prem Black Nitrile Glvs, 2XL
Couldn't load pickup availability
Rubber Insulating Gloves Kit, Class 0
Couldn't load pickup availability
Marker Pen Yellow
Couldn't load pickup availability
Wypall L30 Wiper 16.4 x 9.8"
Couldn't load pickup availability
Paint Marker Yellow
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Specialty Rivet with Plastic Cap Aluminum 3.2mm
Couldn't load pickup availability
Rocker Panel Molding Clip Nylon White 12 x 20mm
Couldn't load pickup availability
Product Description
The Werner 10K Mega-Swivel with Straight Loop Insert Bolt attaches to the Werner Straight Loop Insert that was cast-in place during construction of the surface. The Mega-Swivel is made of steel and plated for corrosion resistance. Includes 5/8 inch bolt and lock washer. The Mega-Swivel design allows full range of motion.• Robust steel design with 360 degree swivel of the forged D-ring
• Includes 5/8 inch x 2-1/2 inch bolt, internal tooth lock washer
• Minimum Breaking Strength (MBS):10,000 lbs.
Technical Specifications
| Item#: | 1648237 |
|---|---|
| Type | Anchor |
| Style | Swivel |
| Material | Steel |
| Length | 5.5 " |
| Width | 3 " |
| Approvals | ANSI Z359.18-2017, OSHA 1910.140/1926.502 |
| Closure Type | Loop/D-Ring |
| Color | Gold |
| D-Rings | D-Ring |
| Connection Size | 2-1/4 " |
| Load Limit | 10000 lb |
| Height | 1 " |
| Quantity Per Package | 1 ea. |
| UNSPSC #: | 46182304 |
| TAA Compliant: | Yes |
