Cross Linked Primary Wire, Polyethylene, 18 AWG, 60 Volts, Yellow, 100' Length, SAE J1128 SXL Cable
(Pack of
1)
• Tough, durable cross-linked, self-extinguishing polyethylene insulation
• Resistant to grease, oil, gasoline, acid, solvents, moisture and aging
• SAE J1128 Type SXL
• Temperature rating: --40°F to 257°F (--40°C to 125°C)
• RoHS compliant
• General-purpose automotive and marine wire for circuit wiring where higher heat resistance is a requirement
• For use at 60V or less
NOTE: Primary wire is not recommended in high voltage applications.
Frequently Bought Together
Cross Linked Primary Wire 10 AWG 100' Purple
Couldn't load pickup availability
Cross Linked Primary Wire 10 AWG 100' Gray
Couldn't load pickup availability
Cross Linked Primary Wire 10 AWG 100' Yellow
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 20 to 18 AWG Black
Couldn't load pickup availability
Energizer® AA Alkaline Battery 1.5V
Couldn't load pickup availability
Lithium Battery #2025 3V
Couldn't load pickup availability
Cross Linked Primary Wire 18 AWG 100' Purple
Couldn't load pickup availability
Cross Linked Primary Wire 10 AWG 100' Red
Couldn't load pickup availability
Plastic Covered Primary Wire 20 AWG 100' Red
Couldn't load pickup availability
Tru-Flate Safety Push-Button Safety Coupler 1/4" Body x 1/2" MNPT
Couldn't load pickup availability
Tru-Flate Safety Push-Button Safety Coupler 1/4" Body x 1/2" FNPT
Couldn't load pickup availability
Standard Industrial Safety Push-Button Safety Coupler 1/2" Body x 3/4" MNPT
Couldn't load pickup availability
Rivet Nylon 1/4"
Couldn't load pickup availability
Shroud Insulating Button Nylon 11/16"
Couldn't load pickup availability
Phillips Truss Head Sheet Metal Screw Steel 15mm
Couldn't load pickup availability
Product Description
• Tough, durable cross-linked, self-extinguishing polyethylene insulation• Resistant to grease, oil, gasoline, acid, solvents, moisture and aging
• SAE J1128 Type SXL
• Temperature rating: --40°F to 257°F (--40°C to 125°C)
• RoHS compliant
• General-purpose automotive and marine wire for circuit wiring where higher heat resistance is a requirement
• For use at 60V or less
NOTE: Primary wire is not recommended in high voltage applications.
Technical Specifications
| Item#: | 18290 |
|---|---|
| Wire Gauge | 18 AWG |
| Color | Yellow |
| Length | 100 ft |
| Maximum Voltage | 60 V |
| Temperature Rating | 257 °F |
| Package Type | 1 Roll |
| Approvals | SAE J1128 Type SXL, RoHS compliant |
| Resists | grease, oil, gasoline, acid, solvents, moisture and aging |
| Style | SXL Cross-Linked Primary Wire |
| Type | Wire |
| UNSPSC #: | 26121524 |
| TAA Compliant: | Yes |
| Weight: | 1.02 lb |
Product Restrictions
