Female Quick Slide Terminal, Nylon Insulated, 22 to 18 AWG, 1/4" Tab Width, Red
(Pack of
100)
SKU:86056M01 Item#: 86056M01
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.
Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
• Female – Superior clamping power even after many connections
Electro-Lok
• Quick Slides offer a durable and reliable connection without sacrificing conductivity
• Manufactured from high-grade copper for the highest conductivity • Annealed to flow freely under crimping pressure for best connection • Electro-tin-plated for greatest corrosion resistance • 600V
Frequently Bought Together
Male Quick Slide Terminal 22 to 18 AWG Clear
$0.00
Couldn't load pickup availability
Male Quick Slide Terminal 16 to 14 AWG Blue
$0.00
Couldn't load pickup availability
Male Disconnect Terminal 16 to 14 AWG Blue
$0.00
Couldn't load pickup availability
Master Series Penlight Flashlight
$0.00
Couldn't load pickup availability
Vision Pro Super
$0.00
Couldn't load pickup availability
Halogen Miniature Bulb 55W 12V
$0.00
Couldn't load pickup availability
Metric Indented Hex Head Bolt with 17mm Washer
$0.00
Couldn't load pickup availability
Front Bumper and Radiator Support Drive Rivet
$0.00
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Blue
$0.00
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Blue
$0.00
Couldn't load pickup availability
Butt Connector 12 to 10 AWG
$0.00
Couldn't load pickup availability
Product Description
Electro-Lok terminals provide a superior solderless crimp terminal connection when compared to other traditional terminal.The butted-seam barrel with a flared seamless brass sleeve provides an extremely strong two-crimp connection.Electro-Lok terminals feature:
• Full-length crimp barrel for excellent electrical contact
• A second crimp at the flared portion of the sleeve that provides mechanical stress relief and vibration-resistance at the junction of the wire insulation and barrel
• Molded see-through nylon insulation that provides high-quality, tough, chemical-resistant electrical insulation for industrial applications
• Female – Superior clamping power even after many connections
Electro-Lok
• Quick Slides offer a durable and reliable connection without sacrificing conductivity
• Manufactured from high-grade copper for the highest conductivity • Annealed to flow freely under crimping pressure for best connection • Electro-tin-plated for greatest corrosion resistance • 600V
Technical Specifications
| Item#: | 86056M01 |
|---|---|
| Type | Crimp |
| Wire Gauge | 22-18 AWG |
| Tab Width | 1/4 " |
| Connection Type | Female |
| Color | Red |
| Approvals | UL, CSA |
| Description | Quick Slide |
| Style | Electro-Lok Quick Slides |
| UNSPSC #: | 39121432 |
| TAA Compliant: | Yes |
| Weight: | 0.29 lb |
