Ford OEM Self-Piercing Rivet, 3.5mm Body Diameter, 2.0mm ID, 5.8mm Head Diameter, Solid Head Style, 4.5mm Overall Length
(Pack of
10)
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.
Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Frequently Bought Together
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
Couldn't load pickup availability
Drive Rivet Nylon M8
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Fender Bumper Shield Retainer 11/16"
Couldn't load pickup availability
Acrysol Auto Body Degreaser 16oz
Couldn't load pickup availability
Fender Apron Drive Rivet 8mm Hole
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 20mm
Couldn't load pickup availability
Grip-Tite Blind Rivet Nylon 13/64"
Couldn't load pickup availability
Leg Retention Style Blind Rivet
Couldn't load pickup availability
Rivet Nylon 17/64"
Couldn't load pickup availability
Product Description
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Technical Specifications
| Item#: | 1637092 |
|---|---|
| Type | Self-Piercing Rivet |
| Body Diameter | 3.5 mm |
| Diameter | 3.5 mm |
| Length | 4.5 mm |
| Make | Ford |
| OEM Number | W718595-S900 |
| Ford OEM Number | W718595-S900 |
| Flange Diameter | 5.8 mm |
| Material | Steel |
| Rivet Length | 4.5 mm |
| I.D. | 2.0 mm |
| Description | Self-Piercing Rivet |
| Quantity Per Package | 10.0000 |
| Head Diameter | 5.8 mm |
| Head Style | Solid |
| UNSPSC #: | 25172502 |
| TAA Compliant: | Yes |
| Weight: | 0.05 lb |
Product Restrictions
