JIS B1189 Small Hex Flange Bolt, Grade 10.9, Alloy Steel, Zinc Finish, Fine Thread, 14mm Across Flats, M10-1.25 x 20mm
(Pack of
10)
JIS Metric Fasteners
Frequently Bought Together
Hex Cap Screw Grade 5 1/4-20 x 1/2"
Item#: FA65000
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M10-1.5 x 50mm
Item#: 59746
Couldn't load pickup availability
DIN 6921 Hex Flange Bolt Grade 8.8 M6-1 x 30mm
Item#: 59410
Couldn't load pickup availability
Blind Rivet Nut Insert Thin Wall M6-1
Item#: 1405793
Couldn't load pickup availability
Hammerlock Cotter Pin Kit 140Pcs
Item#: 97184
Couldn't load pickup availability
Hex Nut Grade 5 Steel 3/8-16
Item#: FA95679
Couldn't load pickup availability
Hex Flange Bolt Grade 8 3/8-16 x 1"
Item#: 86393
Couldn't load pickup availability
Hex Flange Bolt Grade 10.9 M8-1.25 x 35mm
Item#: 59732
Couldn't load pickup availability
Hex Flange Bolt Grade 8 5/16-18 x 1-1/2"
Item#: 51938
Couldn't load pickup availability
Front Fender Push-Type Retainer Nylon 18mm
Item#: KT13984
Couldn't load pickup availability
Fender Splash Shield Push Rivet Nylon 7mm Hole
Item#: KT14296
Couldn't load pickup availability
Miniature Incandescent Bulb 12V 2CP
Item#: P22266
Couldn't load pickup availability
Product Description
JIS Metric FastenersTechnical Specifications
| Item#: | 55607 |
|---|---|
| Type | Hex Flange Bolt |
| Diameter | M10 |
| Thread Pitch | 1.25 mm |
| Thread | Fine |
| Length | 20 mm |
| Finish | Bright Zinc |
| Material | Alloy Steel |
| Grade | 10.9 |
| Flange Diameter | 21 mm |
| Head Style | Small Hex Flange |
| Head Height | 6 mm |
| Across Flats | 14 mm |
| Specifications | JIS B1189 |
| Tensile Strength | 1,040 MPa |
| UNSPSC #: | 31161620 |
| TAA Compliant: | No |
| Weight: | 0.55 lb |
