Male Quick Slide Terminal, Nylon Insulated, 22 to 18 AWG, 1/4" Tab Width, Red
(Pack of
100)
SKU:P35282 Item#: P35282
Visa Crimp™ provides a high-quality crimp terminal connection. The brazed-seam barrel single crimp design will not open from wire pull, vibration or stress, providing a reliable connection.
Visa Crimp™ terminals feature:
• Brazed seam barrel
• Funnel-mouth barrel entry for easy wire insertion
• Long barrel for easier crimping in any position
• Translucent insulation for foolproof crimping; crack- and chemical-resistance
• Male – Dimpled tabs help hold the two connectors together even in high vibration conditions
Visa Crimp™
• Quick Slides offer a durable and reliable connection without sacrificing conductivity
• Manufactured from high-grade copper for the highest conductivity • Annealed to flow freely under crimping pressure for best connection • Electro-tin-plated for greatest corrosion resistance • Meets MIL-T-10727 Specifications
• Maximum voltage rating: 600V at 221°F (105°C); 1,000V in signs, fixtures and luminaries
• Amperage ratings: 26–24 Ga. 3A; 22–18 Ga. 7A; 16–14 Ga. 15A; 12–10 Ga. 30A
• Operating temperature: –40°F to +221°F (–40°C to +105°C)
• Funnel barrel design for easier wire insertion
• Visa Crimp™ insulation for visible crimp and dependable high dielectric strength
• Copper is tempered to provide high conductivity while retaining the high strength required for repeated disconnections and connections
Couldn't load pickup availability
Catalog page#: 2-19
Frequently Bought Together
Female Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Female Disconnect Terminal 22 to 18 AWG Red
Couldn't load pickup availability
Male Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Butt Connector 12 to 10 AWG Yellow
Couldn't load pickup availability
Extension Cord Tri-Tap Adapter 15A 125V
Couldn't load pickup availability
Lithium Coin Cell Battery #2032 3V
Couldn't load pickup availability
Nylon Cable Tie 15-1/4" Black
Couldn't load pickup availability
Fender Splash Shield Retainer Nylon 20mm
Couldn't load pickup availability
Fender Liner Screw Grommet Nylon M5.5
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Female Disconnect Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Female Disconnect Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Product Description
Visa Crimp™ provides a high-quality crimp terminal connection. The brazed-seam barrel single crimp design will not open from wire pull, vibration or stress, providing a reliable connection.Visa Crimp™ terminals feature:
• Brazed seam barrel
• Funnel-mouth barrel entry for easy wire insertion
• Long barrel for easier crimping in any position
• Translucent insulation for foolproof crimping; crack- and chemical-resistance
• Male – Dimpled tabs help hold the two connectors together even in high vibration conditions
Visa Crimp™
• Quick Slides offer a durable and reliable connection without sacrificing conductivity
• Manufactured from high-grade copper for the highest conductivity • Annealed to flow freely under crimping pressure for best connection • Electro-tin-plated for greatest corrosion resistance • Meets MIL-T-10727 Specifications
• Maximum voltage rating: 600V at 221°F (105°C); 1,000V in signs, fixtures and luminaries
• Amperage ratings: 26–24 Ga. 3A; 22–18 Ga. 7A; 16–14 Ga. 15A; 12–10 Ga. 30A
• Operating temperature: –40°F to +221°F (–40°C to +105°C)
• Funnel barrel design for easier wire insertion
• Visa Crimp™ insulation for visible crimp and dependable high dielectric strength
• Copper is tempered to provide high conductivity while retaining the high strength required for repeated disconnections and connections
Technical Specifications
| Item#: | P35282 |
|---|---|
| Type | Crimp |
| Wire Gauge | 22-18 AWG |
| Tab Width | 1/4 " |
| Blade Thickness | 0.032 " |
| Connection Type | Male |
| Color | Red |
| Approvals | UL, CSA |
| Description | Male |
| Style | Visa Crimp Quick Slides |
| UNSPSC #: | 39121432 |
| TAA Compliant: | No |
| Weight: | 0.25 lb |
