Mid-Range Panel-Mount Circuit Breaker, Type I Automatic Reset, 30 Amps, 30 Volts DC, Rounded Profile Body
(Pack of 1)

Item#: 50268

Kent Automotive

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Read More
Check Availability

Frequently Bought Together


Mid-Range Panel-Mount Circuit Breaker Type I 40A

Item#: 50270

Computer-Safe Automotive Logic Probe 18 AWG 6'

Item#: 60615

Post-Style Circuit Breaker without Bracket 15A 12V

Item#: 11145

Lithium Battery #2450 3V

Item#: 1435630

Energizer® AAA Alkaline Battery 1.5V

Item#: 1145994

Tru-Shrink Heat Shrink Tubing 20 to 18 AWG Black

Item#: 61655

Fusible Link 16 AWG 7-1/2"

Item#: 84636

Fusible Link 18 AWG 7"

Item#: 83218

Fusible Link 14 AWG 8-1/2"

Item#: 84637

Phillips Truss Head Sheet Metal Screw Steel 15mm

Item#: P13770

Wheel Opening Drive Rivet Aluminum 5/32"

Item#: P13787

Push-Type Retainer Nylon 20mm

Item#: P23453

Product Description

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Technical Specifications

Item#: 50268
Style Mid-Range Panel-Mounted Circuit Breakers
Amperage 30 A
Volts 32 DC
Approvals Ignition protected (ABYC E-9/SAE J1171)
Description Type I Automatic Reset
Type Electrical
UNSPSC #: 39121601
TAA Compliant: Yes
Weight: 0.09 lb
