Nipple, Bowes, 1/2'' Body, 1-11 Female BSPP, Brass
(Pack of
1.0)
Dual guide sleeve tabs will ensure smooth collar action during connection and disconnection. Push-Twist and Click connection provides a positive lock when connected. Pneumatically energized seal provides an airtight seal at all working pressures. Available safety-lock ring protects against accidental disconnection while coupling is in operation. Used for air hammers and large bore air tools. Used in underground boring, power utilities and equipment rentals.
OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection see Accessories
Locking Mechanism: Latch tabs
Meets MIL-C-3486 for Military applications
Operating Pressure: 300 PSI
Coupled Burst Pressure: 3,000 PSI
Flow: 250 CFM
Dixon: N-Series
Bowes: 51000 Series
Product Description
Dual guide sleeve tabs will ensure smooth collar action during connection and disconnection. Push-Twist and Click connection provides a positive lock when connected. Pneumatically energized seal provides an airtight seal at all working pressures. Available safety-lock ring protects against accidental disconnection while coupling is in operation. Used for air hammers and large bore air tools. Used in underground boring, power utilities and equipment rentals. OSHA Standard 29CFR, 926.302(b)(1) requires that pneumatic tools be secured to the hose or whip by positive means to prevent accidental disconnection see Accessories
Locking Mechanism: Latch tabs
Meets MIL-C-3486 for Military applications
Operating Pressure: 300 PSI
Coupled Burst Pressure: 3,000 PSI
Flow: 250 CFM
Dixon: N-Series
Bowes: 51000 Series
Technical Specifications
Item#: | 1167258 |
---|---|
Type | Nipple |
Style | Bowes |
Body Size | 1/2 " |
Thread Style | Female BSPP |
Thread Size | 1-11 |
Working Pressure | 300 PSI |
Material | Brass |
Length | 3.37 " |
Hex Size | 1-1/2 " |
Locking Mechanism | Latch Tabs |
Flow | 204 ft³/min |
UNSPSC #: | 27131613 |
TAA Compliant: | Yes |
