Push-to-Connect Extended Elbow, Nickel-Plated Brass/PBT Resin, 4mm x M5-0.8, Tube x Metric Male Thread, 150 PSI Working Pressure
(Pack of
10)
SKU:1199979 Item#: 1199979
Designed for pneumatic installations and conveyance of inert gases. Resin Series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.
• Working Temperature: 32°F – 140°F
• Working Pressure: 150 psi
• Suitable Fluids: Compressed Air/Inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel Plated Brass with Resin Body Material constructed of Polybutylene Terephthalate (PBT)
• Gripping Ring: 301 Stainless Steel
• Release Ring: Acetal Plastic
• O-Ring: NBR(Buna-N)
The body is orientable for positioning purposes.
Frequently Bought Together
Nylon Tubing 1/4" OD x 100' Translucent
$0.00
Couldn't load pickup availability
Push-to-Connect Connector, Polyoxymethlene, 1/2 x 1/2"
$0.00
Couldn't load pickup availability
Push-to-Connect Union Elbow, Polyoxymethlene, 1/2 x 1/2"
$0.00
Couldn't load pickup availability
Pipe Bushing Brass 3/4-14 x 3/8-18
$0.00
Couldn't load pickup availability
Pipe Adapter Brass 3/8-18 x 3/8-18
$0.00
Couldn't load pickup availability
Pipe Tee Brass 3/8-18 x 3/8-18 x 3/8-18
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 3/4 to 1-3/4"
$0.00
Couldn't load pickup availability
Slotted Hex Head Hose Clamp 301 SS 3/8 to 7/8"
$0.00
Couldn't load pickup availability
FLEXAIR 3/8" I.D. x 50' air hose
$0.00
Couldn't load pickup availability
Push-to-Connect Connector Brass 3/8 x 3/8"
$0.00
Couldn't load pickup availability
Push-to-Connect Connector Brass 1/8 x 1/8"
$0.00
Couldn't load pickup availability
Push-to-Connect Branch Tee Nylon 5/16 x 5/16 x 1/4"
$0.00
Couldn't load pickup availability
Bumper Drive Rivet Plastic 10mm Hole
$0.00
Couldn't load pickup availability
Bumper Cover Push-Type Retainer Nylon 18mm
$0.00
Couldn't load pickup availability
Shield Push-Type Retainer with Metal Insert
$0.00
Couldn't load pickup availability
Product Description
Designed for pneumatic installations and conveyance of inert gases. Resin Series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.• Working Temperature: 32°F – 140°F
• Working Pressure: 150 psi
• Suitable Fluids: Compressed Air/Inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel Plated Brass with Resin Body Material constructed of Polybutylene Terephthalate (PBT)
• Gripping Ring: 301 Stainless Steel
• Release Ring: Acetal Plastic
• O-Ring: NBR(Buna-N)
The body is orientable for positioning purposes.
Technical Specifications
| Item#: | 1199979 |
|---|---|
| Configuration | Extended Male Elbow |
| Tube Size | 4 mm |
| Thread Size | M5x0.8 |
| Thread Style | Metric |
| Material | Nickel-Plated Brass/PBT Resin |
| Wrench Size | 10 mm |
| Working Pressure | 150 PSI |
| Temperature Range | 32 to 140 °F |
| UNSPSC #: | 40183100 |
| TAA Compliant: | No |
