Rckr Swtch, Single Pole Double Throw, 14V DC 20A , 28V DC 10A , 3 Blade Term, No Markings, Blk, Snap-in Rnd & Frame, On-Off-On
(Pack of
1)
SKU:DY41120042 Item#: DY41120042
• Rating: 14V DC 20A , 28V DC 10A
• Terminal: 0.187" quick-change silver-plated copper alloy
• Actuator Material: Nylon 66
• Operating Temp: -13° – +185°F (-25° – +85°C)
• Circular Panel Cut Out: 0.795" (20.2mm)
• Max Mount Depth: 0.118" (3mm)
Frequently Bought Together
Bumper Radiator and Grille Drive Rivet 7mm Hole
Item#: P85262
$0.00
Couldn't load pickup availability
Push-Type Retainer Nylon 16 x 19mm
Item#: 1468633
$0.00
Couldn't load pickup availability
Bumper Fascia General Purpose Split Rivet 3/16"
Item#: KT13747
$0.00
Couldn't load pickup availability
Product Description
• Rating: 14V DC 20A , 28V DC 10A• Terminal: 0.187" quick-change silver-plated copper alloy
• Actuator Material: Nylon 66
• Operating Temp: -13° – +185°F (-25° – +85°C)
• Circular Panel Cut Out: 0.795" (20.2mm)
• Max Mount Depth: 0.118" (3mm)
Technical Specifications
| Item#: | DY41120042 |
|---|---|
| Style | Rocker Switches- Snap-In Round Rocker/Round Frame |
| Description | Rocker Switches- Screw-In Round Rocker, Single Pole/Single Throw W/No Markings |
| Pole | Single |
| Throw | Double |
| Terminal Connection | 187" Quick-Change Silver-Plated Copper Alloy |
| Switch Positions | On - Off-On |
| Electrical Rating Amps at Given Voltage (DC Current) | 14V DC 20A , 28V DC 10A |
| Material | Nylon 66 |
| Thread | Snap-In |
| Panel Hole Diameter | .795 X .118 " |
| Type | Switches |
| Maximum Mount Depth | .118" (3mm) |
| Circular Panel Cut Out | .795" (20.2mm) |
| UNSPSC #: | 39122200 |
| TAA Compliant: | No |
| Weight: | 0.015 lb |
