Temflex™ 165 Vinyl Electrical Tape, Black, 3/4" Width, 60' Length, 200% Elongation, 32 to 176°F Temperature Rating
(Pack of
10)
SKU:P34103 Item#: P34103
• Exclusive PVC memory provides smooth, tight taping jobs
• Prevents loose wires and connections
• Resists oil, gas, water, grease and acid
• Each roll individually wrapped
• Specially developed for automotive and truck electrical taping and repairs
Frequently Bought Together
Ring Tongue Terminal 22 to 18 AWG Red
Item#: P50441
$0.00
Couldn't load pickup availability
Master Series Handheld Flashlight
Item#: 1635590
$0.00
Couldn't load pickup availability
H7 Halogen Miniature Bulb 55W 12V
Item#: KT13248
$0.00
Couldn't load pickup availability
Fender Liner Screw Grommet Nylon M5.5
Item#: 1457513
$0.00
Couldn't load pickup availability
Air Distributor Defroster Push-Type Retainer
Item#: P85035
$0.00
Couldn't load pickup availability
Molding Clip with Sealer Nylon White 10 x 12mm
Item#: P85218
$0.00
Couldn't load pickup availability
Vinyl Electrical Tape Yellow 3/4" x 66'
Item#: 1145739
$0.00
Couldn't load pickup availability
Vinyl Electrical Tape Brown 3/4" x 66'
Item#: 29415
$0.00
Couldn't load pickup availability
Auto Electric Super Sealant 2-1/2" x 2-1/2'
Item#: 84079
$0.00
Couldn't load pickup availability
Heat Shrink Tubing 22 to 20 AWG Black
Item#: 88827
$0.00
Couldn't load pickup availability
Heat Shrink Tubing 8 to 2 AWG Black
Item#: 51882
$0.00
Couldn't load pickup availability
Heat Shrink Tubing 12 to 6 AWG Black
Item#: 51881
$0.00
Couldn't load pickup availability
Product Description
• Exclusive PVC memory provides smooth, tight taping jobs• Prevents loose wires and connections
• Resists oil, gas, water, grease and acid
• Each roll individually wrapped
• Specially developed for automotive and truck electrical taping and repairs
Technical Specifications
| Item#: | P34103 |
|---|---|
| Manufacturer Model #: | 1700 |
| Type | Individual Roll |
| Style | PVC Electrical Tape |
| Color | Black |
| Dielectric Strength | 1000 V/mil |
| Length | 60 ft |
| Width | 3/4 " |
| Thickness | 7 mil |
| Temperature Range | 32 to 176 °F |
| Celcius Temperature Range | 0 to 80 °C |
| Elongation | 200 % |
| Adhesion to Steel | 22 in. oz. |
| Adhesion to Backing | 22 in. oz. |
| Adhesive Material | Rubber Resin |
| Backing Material | Polyvinyl Chloride |
| Breaking Strength | 17 lb./in. |
| Voltage Rating | 600 V |
| Approvals | ASTM, CSA, MSHA, UL |
| Description | 3/4" x 60' Roll |
| UNSPSC #: | 31201502 |
| TAA Compliant: | Yes |
| Weight: | 1.72 lb |
